DataConnect Category 6A Cable, 4 Pair, F/UTP, CMR
DataConnect Category 6A Premise Horizontal Cable (500MHz), 4 Pair, 23 AWG Solid Bare Copper Conductors, F/UTP - Foil Shielded, Riser-CMR, PVC Jacket
- Availability
- Americas
- Status
- Active
- Orderable items
- 3
Part numbers
DAFR is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | Putup Type | Length | Order |
|---|---|---|---|---|
| DAFR 0101000 | Black | Reel | 1,000 ft | Order online |
| DAFR 0061000 | Blue | Reel | 1,000 ft | Order online |
| DAFR 0091000 | White | Reel | 1,000 ft | Order online |
Specifications
Product Overview
| Suitable Applications | Premise Horizontal Cable, Ethernet up to 10GBASE-T, Wi-Fi 6, Wi-Fi 5, Surveillance, HDBaseT, PoE++, PoE+, PoE, Noisy Environments |
|---|---|
| Patent | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents . |
Construction Details
Conductor
| Size | 23 AWG |
|---|---|
| Stranding | Solid |
| Material | BC - Bare Copper |
| No. of Pairs | 4 |
Insulation
| Material | PO - Polyolefin |
|---|---|
| Color Code | White & Blue, White & Orange, White & Green, White & Brown |
Outer Shield
| Shield Type | Tape |
|---|---|
| Material | Bi-Laminate (Alum+Poly) |
| Coverage | 100% |
Outer Jacket
| Material | PVC - Polyvinyl Chloride |
|---|---|
| Nom. Diameter | 0.265 in (6.73 mm) |
Electrical Characteristics
Electricals
| Max. Conductor DCR | 82 Ohm/km (25 Ohm/1000ft) |
|---|---|
| Max. Capacitance Unbalance | 45 pF/100m |
Delay
| Max. Delay | 537.6 ns/100m |
|---|---|
| Nom. Velocity of Prop. | 70% |
Standards and Compliance
| Plenum Number | DAFP |
|---|
History
| Update and Revision | Revision Number: 0.13 Revision Date: 08-20-2026 |
|---|
