Product Number: 121700A

DataTuff® Cat 5e, 4 Bonded-Pr #24 Sol BC, PO Ins, PVC Jkt, AIA Armor, PVC Jkt, CMG CM

Industrial Ethernet Cat 5e, 4 Bonded-Pair 24AWG (Solid) Bare Copper, PO Insulation, PVC Inner Jacket, Aluminum Interlock Armor, PVC Outer Jacket, CMG CM

Availability: Global
Status: Active
Orderable items: 4

Ships from and sold by A5 IT.

Part numbers

121700A is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #	Color	Putup Type	Length	UPC	Footnote	Order
121700A 0101000	Black	Reel	1,000 ft	612825108962	C Z	Order online
121700A 0103000	Black	Reel	3,000 ft	612825399728	C Z	Order online
121700A 0105000	Black	Reel	5,000 ft	612825108979	C Z	Order online
121700A 0081000	Gray	Reel	1,000 ft	612825108955	C Z	Order online

Specifications

Product Overview

Suitable Applications	harsh environment, IIoT, factory or process automation, IP cameras and devices, data communication, etc. exposure to rodent, crush, or cut through force,
Patent	This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents .

Construction Details

Bonded-Pair	Yes
Overall Cable Diameter (Nominal)	0.553 in (14.0 mm)

Conductor

Element	Pair(s)
Size	24 AWG
Stranding	Solid
Material	BC - Bare Copper
No. of Pairs	4

Insulation

Material	PO - Polyolefin
Color Code	White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown

Inner Jacket

Material	PVC - Polyvinyl Chloride
Nom. Diameter	0.202 in (5.13 mm)
Ripcord	Yes

Armor

Armor Type & Material	AIA - Aluminum Interlock Armor

Outer Jacket

Material	PVC - Polyvinyl Chloride
Nom. Diameter	0.553 in (14.0 mm)

Electrical Characteristics

Electricals

Max. Conductor DCR	93.8 Ohm/km (28.6 Ohm/1000ft)
Max. Capacitance Unbalance	66 pF/ft

Delay

Max. Delay	510 ns/100m
Max. Delay Skew	25 ns/100m
Nom. Velocity of Prop.	70%

High Frequency

Frequency [MHz]	Max. Insertion Loss (Attenuation)	Min. NEXT [dB]	Min. PSNEXT [dB]	Min. ACR [dB]	Min. PSACR [dB]	Min. ACRF (ELFEXT) [dB]	Min. PSACRF (PSELFEXT) [dB]	Min. RL (Return Loss) [dB]	Max./Min. Input Impedance (unFitted) [Ohm]	Max./Min. Fitted Impedance [Ohm]
1	2.0 dB/100m	65.3	65.3	63.3	63.3	63.8	60.8	20	100 ± 12	105 ± 10
4	4.0 dB/100m	56.3	56.3	52.3	52.3	51.7	48.7	23	100 ± 12	100 ± 10
8	5.7 dB/100m	51.8	51.8	46.1	46.1	45.7	42.7	24.5	100 ± 12	100 ± 10
10	6.4 dB/100m	50.3	50.3	43.9	43.9	43.8	40.8	25	100 ± 12	100 ± 10
16	8.1 dB/100m	47.3	47.3	39.1	39.1	39.7	36.7	25	100 ± 12	100 ± 10
20	9.2 dB/100m	45.8	45.8	35.2	35.2	37.7	34.7	25	100 ± 12	100 ± 10
25	10.3 dB/100m	44.3	44.3	34.1	34.1	35.8	32.8	24.3	100 ± 15	100 ± 10
31.25	11.6 dB/100m	42.9	42.9	31.3	31.3	33.9	30.9	23.6	100 ± 15	100 ± 10
62.5	16.8 dB/100m	38.4	38.4	21.6	21.6	27.8	24.8	21.5	100 ± 15	100 ± 10
100	21.7 dB/100m	35.3	35.3	17.1	17.1	23.8	20.8	20.1	100 ± 15
155	27.7 dB/100m	32.5	32.5	4.7	4.7	19.9	16.9	19	100 ± 18
200	32 dB/100m	30.8	30.8	3	3	17.7	14.7	19	100 ± 20
250	36.4 dB/100m	29.3	29.3	0	0	15.8	12.8	18	100 ± 20
300	40.5 dB/100m	28.2	28.2	0	0	14.2	11.2	18	100 ± 20
310	41.3 dB/100m	27.9	27.9			13.9	10.9	18	100 ± 20
350	44.3 dB/100m	27.2	27.2			12.9	9.9	17	100 ± 22

Voltage

UL Voltage Rating	300 V (CM)
Voltage Rating	300 V (CMG-HL)

Mechanical Characteristics

Max. Pull Tension	40 lbs (18 kg)
Bulk Cable Weight	123 lbs/1000ft

Temperature

UL Temperature	60°C
Operating	-40°C To +75°C
Installation	-25°C To +75°C
Storage	-25°C To +85°C

Bend Radius

Stationary Min.	6.5 in (170 mm)

Standards and Compliance

Environmental Suitability	Indoor/Outdoor, Indoor, Outdoor, Sunlight Resistance, Oil Resistance, Aerial - When supported by messenger wire
Flammability / Reaction to Fire	UL 1685 (UL Loading), FT4
NEC / UL Compliance	Article 800, CM
CEC / C(UL) Compliance	CMG, HL.
IEEE Compliance	IEEE 802.3bt Type 1, Type 2, Type 3
Data Category	Category 5e
European Directive Compliance	EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16
APAC Compliance	China RoHS II (GB/T 26572-2011)

Product Notes

Notes	US Patent #'s 5606151; 5734126 Operating temperatures are subject to length de-rating. Cable passes -40C Cold Bend per UL 1581.

History

Update and Revision	Revision Number: 0.574 Revision Date: 02-20-2026
Footnote	C - CRATE REEL PUT-UP., Z - FINAL PUT-UP MAY VARY (= OR -) 10% FOR SPOOLS OR REELS AND (+ OR -) 5% FOR UNREEL CARTONS FROM LENGTH SHOWN.
