Fieldbus, 1 Pr #18 Str TC, XLPO Ins, OS, TPE Jkt, CMG
Fieldbus, 1 Pair 18AWG (7x26) Tinned Copper, XLPO Insulation, Overall Beldfoil® Shield, TPE Outer Jacket, CMG
- Availability
- Global
- Status
- Active
- Orderable items
- 3
Part numbers
2100A is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | Put-Up Type | Length | UPC | Order |
|---|---|---|---|---|---|
| 2100A 0065000 | Blue, Light | Reel | 5,000 ft | 612825128786 | Order online |
| 2100A 0031000 | Orange | Reel | 1,000 ft | 612825128755 | Order online |
| 2100A 0035000 | Orange | Reel | 5,000 ft | 612825128762 | Order online |
Specifications
Product Overview
| Suitable Applications | harsh environment digital and serial two-way communication, oil and gas extraction and refining sites, petrochemical, Profibus process automation or Foundation FieldBus process automation, extreme temperature environments, exposure to humidity/moisture, dust, and oil, remote locations long distance applications, etc. |
|---|
Physical Characteristics (Overall)
| Conductor Count | 2 |
|---|---|
| Total Number of Pairs | 1 |
Conductor
| Element | Pair(s) |
|---|---|
| AWG | 18 |
| Stranding | 7x26 |
| Material | TC - Tinned Copper |
Insulation
| Material | XLPE - Cross-Linked Polyethylene (Thermoset) |
|---|
Color Chart
| Number | 1 |
|---|---|
| Color | Blue, Orange and Numbered |
Inner Shield
| Type | Material | Material Trade Name | Coverage [%] | Drainwire AWG | Drainwire Construction n x D |
|---|---|---|---|---|---|
| Tape | Bi-Laminate (Alum+Poly) | Beldfoil® | 100% | 20 | 7x28 |
| Tinned Copper (TC) |
Outer Jacket
| Material | TPE - Thermoplastic Elastomer |
|---|---|
| Nominal Diameter | 0.319 in |
| Ripcord | Yes |
Electrical Characteristics
| Electrical Characteristics Notes | Max Propagation Delay Change From 7.812 kHz to 39.06 kHz: 518 pS/ft |
|---|---|
| Other Electrical Characteristic 2 | 31.25 KBits/sec |
Conductor DCR
| Nominal Conductor DCR | 5.86 Ohm/1000ft |
|---|
Capacitance
| Max. Capacitance Unbalance | 1.2 pF/ft |
|---|---|
| Nom. Capacitance Conductor to Conductor | 22 pF/ft |
Inductance
| Nominal Inductance | 0.22 μH/ft |
|---|
Impedance
| Nominal Characteristic Impedance | 100 Ohm |
|---|
High Frequency (Nominal/Typical)
| Nom. Insertion Loss | 0.08 dB/100ft |
|---|
Delay
| Nominal Velocity of Propagation (VP) [%] | 64% |
|---|
High Frequency
| Max. Insertion Loss (Attenuation) | 0.091 dB/100ft |
|---|---|
| Max./Min. Input Impedance (unFitted) | 100 Ohm |
Current
| Element | Per Conductor |
|---|---|
| Max. Recommended Current [A] | 8.7 Amps per Conductor |
Voltage
| Description | CSA CIC type TC |
|---|---|
| UL Voltage Rating | 300 V |
| Voltage Rating [V] | 300 V RMS |
Temperature Range
| Installation Temp Rating | -25°C |
|---|---|
| Installation Temperature Range | -25°C |
| UL Temperature Rating | 90°C Wet/Dry |
| Operating Temperature Range | -25°C Cold Impact -40°C to +90°C -55°C Cold Bend |
Mechanical Characteristics
| UV Resistance | Yes |
|---|---|
| Bulk Cable Weight | 51 lbs/1000ft |
| Maximum Recommended Pulling Tension | 57 lbs |
| Minimum Minor Axis Bend Radius | 3.25 in |
Standards
| NEC Articles | Article 725, Article 727, Article 800 |
|---|---|
| NEC/(UL) Compliance | CMG, ITC, PLTC |
| CEC/C(UL) Compliance | CIC, TC |
| CSA AWM Compliance | AWM I A/B II A/B, C22.2 #230 Type TC; C22.2#239 Type CIC |
Applicable Environmental and Other Programs
| EU Directive 2000/53/EC (ELV) | Yes |
|---|---|
| EU Directive 2011/65/EU (RoHS 2) | Yes |
| EU Directive 2012/19/EU (WEEE) | Yes |
| EU Directive 2015/863/EU (RoHS 2 amendment) | Yes |
| EU Directive Compliance | EU Directive 2003/11/EC (BFR) |
| EU CE Mark | Yes |
| MII Order #39 (China RoHS) | Yes |
Suitability
| Suitability - Indoor | Yes |
|---|---|
| Suitability - Oil Resistance | Yes |
| Suitability - Outdoor | Yes |
| Suitability - Sunlight Resistance | Yes |
Flammability, LS0H, Toxicity Testing
| UL Flammability | UL1685 FT4 Loading |
|---|---|
| IEC Flammability | IEC 60332-3-24 |
| UL voltage rating | 300 V RMS |
Plenum/Non-Plenum
| Plenum (Y/N) | No |
|---|
History
| Update and Revision | Revision Number: 0.660 Revision Date: 06-10-2026 |
|---|
