EDAB2xxx - Series
Bases for E-Serie Cabinets with knockouts for cable entry. The base is constructed out of two side profiles which correspond to the depth of the cabinet, and two cover panels (front and back) with a corresponding width. .
- Availability
- EMEA
- Status
- Active
- Orderable items
- 12
Part numbers
BASES E-SERIES is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Width | Depth | Color | Application | Order |
|---|---|---|---|---|---|
| EDAB2611 | 600 | 1,000 | Gray | E-Series Cabinets | Order online |
| EDAB2612 | 600 | 1,000 | Black | E-Series Cabinets | Order online |
| EDAB2621 | 600 | 1,200 | Gray | E-Series Cabinets | Order online |
| EDAB2622 | 600 | 1,200 | Black | E-Series Cabinets | Order online |
| EDAB2681 | 600 | 800 | Gray | E-Series Cabinets | Order online |
| EDAB2682 | 600 | 800 | Black | E-Series Cabinets | Order online |
| EDAB2811 | 800 | 1,000 | Gray | E-Series Cabinets | Order online |
| EDAB2812 | 800 | 1,000 | Black | E-Series Cabinets | Order online |
| EDAB2821 | 800 | 1,200 | Gray | E-Series Cabinets | Order online |
| EDAB2822 | 800 | 1,200 | Black | E-Series Cabinets | Order online |
| EDAB2881 | 800 | 800 | Gray | E-Series Cabinets | Order online |
| EDAB2882 | 800 | 800 | Black | E-Series Cabinets | Order online |
Specifications
Application
| Environmental Space | Indoor |
|---|
Construction and Dimensions
| Overall Height | 120 mm |
|---|
Mechanical Construction
| Mechanical Construction Note | TIP: The base is prepared for installation of stabilisers EDAB101x, which are highly recommended to use on cabinets with sliding servers. |
|---|
Mechanical Characteristics
| Load Capacity | 1900 kg |
|---|
Environmental and Overall Characteristics
| Finish | Powder Coated |
|---|---|
| Material | Steel |
Standards
| EU Directive 2011/65/EU (RoHS 2) | Yes |
|---|---|
| MII Order #39 (China RoHS) | EUP 50 |
Related Part Numbers
| Included Parts | 2x side base profile with a cable entry (with knockout-type blanking panels), 2x cover with cable entry (with knockout-type blanking panels), 1 cover with filter, 1 anti dust brush, fasteners |
|---|---|
| Packaging | Individually packed. |
| Update and Revision | Revision Number: 0.194 Revision Date: 05-12-2026 |
