Product Number: 25000UE

Security & Sound, #12-2c, BC, Unshielded, CMR

Security & Commercial Audio Cable, Riser-CMR, 2-12 AWG stranded bare copper conductors with PVC insulation, PVC jacket with ripcord, Aluminum interlocking armor

Availability: Global
Status: Active
Orderable items: 1

Ships from and sold by A5 IT.

Part numbers

25000UE is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #	Color	Putup Type	Length	UPC	Footnote	Order
25000UE 0001000	None	Reel	1,000 ft	612825131991	C	Order online

Specifications

Product Overview

Suitable Applications	Security System, Intercom/PA, Audio/Speaker, Power-Limited Controls

Construction Details

Conductor

Element	Pair(s)
No. of Elements	1
Size	12 AWG
Stranding	19x25
Material	BC - Bare Copper

Insulation

Element	Pair(s)
Material	PP - Polypropylene
Nom. Thickness	0.011 in (0.28 mm)
Nom. Insulation Diameter	0.113 in (2.87 mm)
Color Code	Black & White

Outer Shield

Material	No Shield

Inner Jacket

Material	PVC - Polyvinyl Chloride
Nom. Thickness	0.17 in (4.3 mm)
Nom. Diameter	0.260 in (6.60 mm)
Ripcord	Yes
Color	Gray

Armor

Type of Armor	Interlocked
Material	Aluminum
Diameter over Armoring	0.471 in

Electrical Characteristics

Electricals

Nom. Conductor DCR	1.6 Ohm/1000ft (5.2 Ohm/km)
Nom. Capacitance Cond-to-Cond	24 pF/ft (79 pF/m)
Nom. Inductance	0.15 μH/ft (0.49 μH/m)
Max. Current	12 Amps per Conductor at 25oC

Voltage

UL Voltage Rating	300 V

Mechanical Characteristics

Max. Pull Tension	152 lbs (68.9 kg)
Bulk Cable Weight	65 lbs/1000ft (97 kg/km)

Temperature

UL Temperature	75°C
Operating	-20°C To +75°C

Bend Radius

Stationary Min.	3.76 in (95.5 mm)
Installation Min.	3.76 in (95.5 mm)

Standards and Compliance

Environmental Suitability	Riser, Indoor
Flammability / Reaction to Fire	UL1666 Vertical Riser, FT4
NEC / UL Compliance	Article 760, CL3R, FPLR
European Directive Compliance	EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
APAC Compliance	China RoHS II (GB/T 26572-2011)
