Indoor OptiTuffTM Mini Fiber OS2 12 Fibers OFNP Non-Unitized
FX Indoor, OptiTuffTM Mini Fiber, OS2, 12 Fibers, OFNP, Non-Unitized, Yellow Jacket
- Availability
- Americas
- Status
- Active
- Orderable items
- 1
Part numbers
FISX012W0 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | Putup Type | Order |
|---|---|---|---|
| FISX012W0 | Yellow | Reel | Order online |
Specifications
Product Overview
| Product Category | OptiTuffTM Mini Fiber Cable |
|---|---|
| Suitable Applications | Raised floor, Data Centers, POL/POLAN, FTTx |
Fiber Specifications
| Fiber Type | OS2, G.657.A1, G.652.D |
|---|---|
| Fiber Diameter | 250 μm |
| Fiber Count | 12 |
| Fiber Color Coding | TIA-598-D |
Armor Specifications
| Armor Type and Material | ADA - All-Dielectric Armor |
|---|
Outer Jacket Specifications
| Strength Member | Aramid Yarns |
|---|---|
| Jacket Material | PVDF - Polyvinylidene Fluoride |
| Nom. Diameter | 0.156 in (4.0 mm) |
| Outer Jacket Color | Yellow |
Optical Characteristics
| Wavelength | 1310 nm | 1550 nm |
|---|---|---|
| Max. Attenuation | 0.40 dB/km | 0.30 dB/km |
| 10 Gigabit Ethernet Performance | 10,000 m | 50,000 m |
| 40 Gigabit Ethernet Performance | 10,000 m | -- |
| 100 Gigabit Ethernet Performance | 10,000 m | -- |
Mechanical Characteristics
| Minimum Bend Radius During Installation | 3.75x Cable OD |
|---|---|
| Minimum Bend Radius During Operation | 3.75x Cable OD |
| Max. Tensile Strength During Installation | 100 N (25 lbf) |
| Max. Tensile Strength During Operation | 45 N (10 lbf) |
| Crush Resistance | 220 N/cm |
| Crush Resistance (Recoverable Signal <lt/> +0.5 dB) | 2500 N/cm |
| Bulk Cable Weight | 8 lbs/kft (12 kg/km) |
Temperature Range
| Installation Temperature Range | -10°C to +60°C |
|---|---|
| Operating Temperature Range | -20°C to +70°C |
| Storage Temperature Range | -40°C to +70°C |
Standards and Compliance
| Environmental Suitability | Indoor |
|---|---|
| Flammability / Reaction to Fire | NFPA 262 |
| NEC / UL Compliance | OFNP |
| CEC / C(UL) Compliance | FT6. |
| ICEA Compliance | S-83-596 |
| TIA/EIA Compliance | 568.3, 598-D |
| Telcordia Compliance | GR-409 |
| European Directive Compliance | EU Directive 2015/863/EU (RoHS 2 amendment) |
History
| Update and Revision | Revision Number: 0.205 Revision Date: 05-05-2026 |
|---|
