RailTuff SPE 30mGb 24AWG STR SF/UTP E-Beam XL-LSZH, AWM STYLE 22303, EN 45545-2 Hazard Level HL1-HL3
RailTuff SPE 30mGb 24AWG STR SF/UTP E-Beam XL-LSZH, AWM STYLE 22303, EN 45545-2 Hazard Level HL1-HL3
- Availability
- Global
- Status
- Active
- Orderable items
- 1
Part numbers
BE43910 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | Putup Type | Length | EAN | Order |
|---|---|---|---|---|---|
| BE43910-A500 | Black | Reel | 500 m | 8719605197917 | Order online |
Specifications
Product Overview
| Suitable Applications | 1 single pair Ethernet up to 600 MHz accord. IEEE 802.3bp (1000BASE-T1) |
|---|
Construction Details
Conductor
| Size | 24 AWG |
|---|---|
| Stranding | 7x0.20 mm |
| Material | TC - Tinned Copper |
| No. of Pairs | 1 |
Insulation
| Material | PP - Polypropylene |
|---|---|
| Nom. Insulation Diameter | 1.65 mm (0.0650 in) |
| Color Code | White, Blue |
Outer Shield
| Shield Type | Material |
|---|---|
| Tape | Bi-Laminate (Alum+Poly) |
| Braid | Tinned Copper (TC) |
Outer Jacket
| Material | XLPE - Cross Linked Polyethylene |
|---|---|
| Nom. Diameter | 4.80 mm (0.189 in) |
Electrical Characteristics
Electricals
| Max. Conductor DCR | 94.2 Ohm/km (28.7 Ohm/1000ft) |
|---|---|
| Max. Capacitance Unbalance | 160 pF/100m |
| Nom. Characteristic Impedance | 100 Ohm |
Delay
| Frequency | 4 MHz |
|---|---|
| Max. Delay | 552 ns/100m |
High Frequency
| Frequency [MHz] | Max. Insertion Loss (Attenuation) [dB/100m] | Min. RL (Return Loss) [dB] | Min. TCL [dB] | Min. ELTCTL [dB] |
|---|---|---|---|---|
| 1 | 3.0 | 20 | 40 | 40 |
| 10 | 8.7 | 25 | 35 | 20 |
| 20 | 12.3 | 25 | 30.5 | 13.9 |
| 600 | 70.6 | 15.6 | 8.3 | 5 |
Mechanical Characteristics
Temperature
| Operating | -40°C to + 80°C |
|---|
Standards and Compliance
| Flammability / Reaction to Fire | FT 2, IEC 60332-1-2, IEC 60332-3-25, IEC 60332-3-22, EN 50305 |
|---|---|
| Data Category | SPE 1000 Mbps |
| CENELEC Compliance | EN 45545-2 |
| European Halogen Free Standards | IEC 60754-2 - Halogen Acid Gas Amount - Max. Conductivity = 10 μS/mm, IEC 60754-2 - Halogen Acid Gas Amount - Min. pH = 4.3, IEC 61034-2 - Smoke Density Min. Transmittance = 70% |
History
| Update and Revision | Revision Number: 0.103 Revision Date: 02-20-2026 |
|---|
