DataTuff Ind SPE cable 10Mbps 1km, SF/UTP, AWG18 Solid, PVC
DataTuff Ind SPE cable 10Mbps 1km, SF/UTP, AWG18 Solid, PVC
- Availability
- Asia Pacific
- Status
- Active
Specifications
Product Overview
| Suitable Applications | 1 single pair Ethernet up to 20 MHz |
|---|
Construction Details
Conductor
| Element | Pair(s) |
|---|---|
| Size | 18 AWG |
| Stranding | Solid |
| Material | BC - Bare Copper |
| No. of Pairs | 1 |
Insulation
| Element | Pair(s) |
|---|---|
| Material | PE - Polyethylene (Foam) |
| Nom. Insulation Diameter | 2.45 mm (0.0965 in) |
| Color Code | White & Blue |
Outer Shield
| Shield Type | Material | Coverage |
|---|---|---|
| Tape | Polyester | 100% |
| Tape | Bi-Laminate (Alum+Poly) | 100% |
| Braid | Tinned Copper (TC) | 80% |
Outer Jacket
| Material | PVC - Polyvinyl Chloride |
|---|---|
| Nom. Diameter | 7.1 mm (0.28 in) |
Electrical Characteristics
Electricals
| Max. Conductor DCR | 21.4 Ohm/km at 20°C |
|---|---|
| Max. Capacitance Unbalance | 160 pF/100m |
High Frequency
| Frequency [MHz] | Max. Insertion Loss (Attenuation) | Min. RL (Return Loss) [dB] | Min. TCL [dB] | Min. ELTCTL [dB] | Max. Surface Transfer Impedance | Min. Coupling Attenuation [dB] |
|---|---|---|---|---|---|---|
| 0.1 | 1.02 | 15 | 85 | |||
| 1 | 1.44 | 20 | 40 | 35 | 50 | 85 |
| 4 | 2.60 | 23 | 31 | 23 | 76 | 79 |
| 10 | 4.05 | 25 | 25 | 15 | 100 | 75 |
| 20 | 5.75 | 25 | 20 | 9 | 155 | 72 |
| 30 | 200 |
Voltage
| UL Voltage Rating | 300 V |
|---|
Mechanical Characteristics
Temperature
| Operating | -20°C to +80°C |
|---|
Standards and Compliance
| Environmental Suitability | Sunlight Resistance |
|---|---|
| Flammability / Reaction to Fire | UL 1685 Loading, VW-1 FT1 |
| NEC / UL Compliance | CM, PLTC |
| AWM Compliance | AWM 21026, AWM I/II A/B |
| Data Category | SPE 10 Mbps |
| ISO/IEC Compliance | IEC 61156-13, UL 758 |
History
| Update and Revision | Revision Number: 0.23 Revision Date: 02-26-2026 |
|---|
