DataTuff Ind SPE 400m10Mb 22AWG STR SF/UTP LSZH
DataTuff Ind SPE 400m10Mb 22AWG STR SF/UTP LSZH
- Availability
- Global
- Status
- Active
Specifications
Product Overview
| Suitable Applications | Long distance sensors in harsh environment at Industrial edge, 1 single pair Ethernet up to 20 MHz |
|---|
Construction Details
| Overall Cable Diameter (Nominal) | 5.3 mm (0.21 in) |
|---|
Conductor
| Size | 22 AWG |
|---|---|
| Stranding | 7x0.25 mm |
| Material | TC - Tinned Copper |
Insulation
| Material | PE - Polyethylene (Foam) |
|---|---|
| Nom. Insulation Diameter | 1.65 mm (0.0650 in) |
| Color Code | White, Blue |
Outer Shield
| Shield Type | Material | Coverage | Notes |
|---|---|---|---|
| Tape | Polyester | 100% | |
| Tape | Bi-Laminate (Alum+Poly) | 100% | |
| Braid | Tinned Copper (TC) | 80% | 23 AWG Stranded Drain wire along with shielding |
Outer Jacket
| Material | LSZH - Low Smoke Zero Halogen (Flame Retardant) |
|---|
Electrical Characteristics
Electricals
| Max. Conductor DCR | 59.4 Ohm/km at 20°C |
|---|---|
| Max. Capacitance Unbalance | 160 pF/100m |
| Nom. Characteristic Impedance | 100 Ohm |
High Frequency
| Frequency [MHz] | Max. Insertion Loss (Attenuation) | Min. RL (Return Loss) [dB] | Min. TCL [dB] | Min. ELTCTL [dB] | Max. Surface Transfer Impedance | Nom. Characteristic Impedance [Ohm] |
|---|---|---|---|---|---|---|
| 0.1 | 1.5 | 15 | 50 | 55 | ||
| 1 | 2.2 | 20 | 40 | 35 | 50 | |
| 4 | 3.9 | 23 | 31 | 23 | 75.9 | |
| 10 | 6.1 | 25 | 25 | 15 | 100 | |
| 20 | 8.6 | 25 | 20.5 | 9 | 154.9 | |
| 100 |
Voltage
| UL Voltage Rating | 300 V |
|---|---|
| Breakdown Voltage | 2 Kvac/min. |
Mechanical Characteristics
Temperature
| Operating | -20°C To +80°C |
|---|
Standards and Compliance
| Flammability / Reaction to Fire | FT2 |
|---|---|
| AWM Compliance | AWM 21307 |
| Data Category | SPE 10 Mbps |
| ISO/IEC Compliance | IEC 61156-xx, UL 758 |
| APAC Compliance | China RoHS II (GB/T 26572-2011) |
Product Notes
| Notes | Flame Test: EN50575 Dca-s2,d2,a2 |
|---|
History
| Update and Revision | Revision Number: 0.17 Revision Date: 04-02-2026 |
|---|
