CAT7 Ethernet Railcable 4PR AWG26/7 S/FTP X-FRNC/LSZH
CAT7 4 Pair 26AWG Stranded Tinned Copper Conductor, Foam Polyolefin Insulated, Individually Pair shielded with AL-mylar tape binder & Overall Shieled with Al-mylar + ATC wire braid & Overall E-Beam Cross Linked/LSZH Jacket Ethernet RailCable.
- Availability
- Global
- Status
- Active
Specifications
Product Overview
| Suitable Applications | For railway Ethernet Networking:10Base-T, 100Base-TX, 1000Base-T, 10GBase-T. |
|---|
Construction Details
| Outer Jacket1 Table Notes | E-Beam Cross Linked/LSZH as Jacket material |
|---|---|
| Overall Cable Diameter (Nominal) | 7.0 mm (0.28 in) |
Conductor
| Size | 26 AWG |
|---|---|
| Stranding | 7x0.16 mm |
| Material | TC - Tinned Copper |
| No. of Pairs | 4 |
Insulation
| Element | Pair(s) |
|---|---|
| Material | PO - Polyolefin (Foam) |
| Nom. Insulation Diameter | 1.08 mm (0.0425 in) |
| Color Code | White, Blue, Orange, Green, Brown |
Inner Shield
| Element | Each Pair |
|---|---|
| Shield Type | Tape |
| Material | Bi-Laminate (Alum+Poly) |
Outer Shield
| Shield Type | Material | Coverage | Notes |
|---|---|---|---|
| Tape | Bi-Laminate (Alum+Poly) | ||
| Braid | Tinned Copper (TC) | 80% | A layer of Flame retardant tape wrapped over outer shield |
Outer Jacket
| Separator | Tape |
|---|---|
| Material | LSZH - Low Smoke Zero Halogen (Flame Retardant) |
Electrical Characteristics
Electricals
| Max. Conductor DCR | 145 Ohms @ 20 Deg C |
|---|---|
| Max. Mutual Capacitance | 56 pF/m (17 pF/ft) |
High Frequency
| Frequency | Max. Insertion Loss (Attenuation) [dB/100m] | Min. NEXT [dB] | Min. PSNEXT [dB] | Min. FEXT [dB] | Min. RL (Return Loss) [dB] | Max./Min. Input Impedance (unFitted) [Ohm] |
|---|---|---|---|---|---|---|
| 4 | 5.6 | 78 | 75 | 70 | 23 | 115.2/86.8 |
| 10 MHz | 8.8 | 78 | 75 | 70 | 25 | 111.9/88.8 |
| 20 MHz | 12.4 | 78 | 75 | 70 | 25 | 111.9/89.4 |
| 25 MHz | 13.9 | 78 | 75 | 70 | 25 | 113.2/88.3 |
| 31.25 MHz | 15.6 | 78 | 75 | 70 | 23.3 | 114.6/81.2 |
| 62.5 MHz | 22.3 | 75.5 | 72.5 | 70 | 20.7 | 120.2/83.2 |
| 100 MHz | 28.5 | 72.4 | 69.4 | 70 | 19 | 125.3/79.8 |
| 250 MHz | 46.5 | 66.4 | 63.4 | 70 | 15.6 | 140/71.4 |
| 300 MHz | 51.3 | 65.2 | 62.2 | 70 | 15.6 | 139.98 /71.5 |
| 600 MHz | 75.1 | 60.7 | 57.7 | 70 | 15.6 | 139.8/71.5 |
Voltage
| Voltage Rating | 300 V |
|---|---|
| Breakdown Voltage | 1 KV DC/min |
Mechanical Characteristics
Temperature
| Operating | -40°C to +80°C |
|---|
Standards and Compliance
| Flammability / Reaction to Fire | IEC 60332-3-25, IEC 60332-1-2 |
|---|---|
| Data Category | Category 7 |
| ISO/IEC Compliance | IEC 61156-6 |
| European Halogen Free Standards | IEC 60754-1 - Halogen Amount = 0.5%, IEC 60754-2 - Halogen Acid Gas Amount - Max. Conductivity = 10 μS/mm, IEC 60754-2 - Halogen Acid Gas Amount - Min. pH = 4.3 |
| Other Standard Compliance(s) | EN 45545-2 Hazard Level HL1-HL3, TJ/CL 313 |
History
| Update and Revision | Revision Number: 0.20 Revision Date: 02-26-2026 |
|---|
