Lead Wire, 0.4mm2 Solid CN, PVC Ins, 70°C
PVC 0.4mm CuNi
- Availability
- EMEA
- Status
- Active
- Orderable items
- 4
Part numbers
BE43007 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | Putup Type | Length | EAN | Order |
|---|---|---|---|---|---|
| BE43007.0010K | Black | Reel | 10,000 m | 8719605026293 | Order online |
| BE43007.0210K | Brown | Reel | 10,000 m | 8719605026316 | Order online |
| BE43007.0310K | Green | Reel | 10,000 m | 8719605026323 | Order online |
| BE43007.0110K | White | Reel | 10,000 m | 8719605026309 | Order online |
Specifications
Product Overview
| Suitable Applications | Single core non-sheathed cable with solid conductor for internal wiring for conductor temperatures up to 70C |
|---|
Construction Details
| Conductor Table Notes | Alloy is Copper-Nickel |
|---|
Conductor
| Stranding | Solid |
|---|---|
| Material | BCA - Bare Copper Alloy |
Insulation
| Material | PVC - Polyvinyl Chloride |
|---|---|
| Nom. Thickness | 0.41 mm (0.016 in) |
| Nom. Insulation Diameter | 0.82 mm (0.032 in) |
Standards and Compliance
| Environmental Suitability | Indoor |
|---|---|
| Flammability / Reaction to Fire | VW-1 |
History
| Update and Revision | Revision Number: 0.148 Revision Date: 02-20-2026 |
|---|
