Lead Wire, 0.4 mm BC, PVC Ins
0.4B PVC IEC 189/3 70C
- Availability
- EMEA
- Status
- Active
- Orderable items
- 4
Part numbers
BE41138 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | Putup Type | Length | EAN | Order |
|---|---|---|---|---|---|
| BE41138.0310K | Blue | Reel | 10,000 m | 8719605024770 | Order online |
| BE41138.0210K | Gray | Reel | 10,000 m | 8719605024763 | Order online |
| BE41138.0110K | Red | Reel | 10,000 m | 8719605024756 | Order online |
| BE41138.0010K | Yellow | Reel | 10,000 m | 8719605024749 | Order online |
Specifications
Product Overview
| Suitable Applications | IEC 189-3, VMD 70C rated 300/500V |
|---|
Construction Details
Conductor
| Stranding | Solid |
|---|---|
| Material | BC - Bare Copper |
Insulation
| Material | PVC - Polyvinyl Chloride |
|---|---|
| Nom. Thickness | 0.2 mm (0.0079 in) |
| Nom. Insulation Diameter | 0.82 mm (0.032 in) |
Electrical Characteristics
Electricals
| Max. Conductor DCR | 144 Ohm/km |
|---|
Standards and Compliance
| Environmental Suitability | Indoor |
|---|---|
| European Directive Compliance | EU CE Mark |
History
| Update and Revision | Revision Number: 0.157 Revision Date: 02-20-2026 |
|---|
