Product Number: 8453

Portable Cordage, 3 C #18 Str TC, EPDM Ins, Rubber Jkt, UL Type SV

Name: Belden 8453
Brand: Belden
SKU: 8453

Portable Cordage, 3 Conductor 18AWG (41x34) Tinned Copper, EPDM Insulation, Rubber Outer Jacket, UL Type SV

Ships from and sold by A5 IT.

Part numbers

8453 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #	Color	Putup Type	Length	UPC	Order
8453 010100	Black	Reel	100 ft	612825207818	Order online
8453 010500	Black	Reel	500 ft	612825207825	Order online

Suitable Applications	Junior light-duty vacuum cord(300V), Other light-duty equipements

Overall Cable Diameter (Nominal)	0.256 in (6.50 mm)

Element	Conductor(s)
Material	EPDM - Ethylene Propylene Diene Monomer
Nom. Thickness	0.018 in (0.46 mm)
Nom. Insulation Diameter	0.083 in (2.1 mm)
Color Code	Black, White, Green

Separator	Cotton Serve
Material	SBR - Styrene Butadiene Rubber
Nom. Thickness	0.036 in (0.91 mm)
Nom. Diameter	0.256 in (6.50 mm)

Element	Nom. Conductor DCR	Max. Current
Conductor(s)	7.3 Ohm/1000ft	10 Amps per Conductor at 25oC (7 Amps over 50 ft)
		7 Amps per conductor @ 25°C over 50 ft.

UL Voltage Rating	300 V

Max. Pull Tension	62 lbs (28 kg)
Bulk Cable Weight	42 lbs/1000ft

UL Temperature	60°C
Operating	-40°C to +60°C

Stationary Min.	2.6 in (66 mm)
Installation Min.	2.6 in (66 mm)

Environmental Suitability	Indoor (Not Riser or Plenum), Indoor
NEC / UL Compliance	Article 400, SV
AWM Compliance	SV
CEC / C(UL) Compliance	LL7874.
European Directive Compliance	EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
APAC Compliance	China RoHS II (GB/T 26572-2011)
