Portable Cordage, 3 C #18 Str BC, PVC Ins, PVC Jkt, UL Type SVT
Portable Cordage, 3 Conductor 18AWG (42x34) Bare Copper, PVC Insulation, PVC Outer Jacket, UL Type SVT
- Availability
- Global
- Status
- Active
- Orderable items
- 1
Part numbers
19402 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | Putup Type | Length | UPC | Footnote | Order |
|---|---|---|---|---|---|---|
| 19402 010250 | Black | Reel | 250 ft | 612825127048 | F | Order online |
Specifications
Product Overview
| Suitable Applications | Portable cordage for supplying power to appliances and tools |
|---|
Construction Details
| Overall Cable Diameter (Nominal) | 0.253 in (6.43 mm) |
|---|
Conductor
| Element | Conductor(s) |
|---|---|
| No. of Elements | 3 |
| Size | 18 AWG |
| Stranding | 42x34 |
| Material | BC - Bare Copper |
| Notes | 0.824mm2 |
Insulation
| Element | Conductor(s) |
|---|---|
| Material | PVC - Polyvinyl Chloride |
| Nom. Thickness | 0.018 in (0.46 mm) |
| Nom. Insulation Diameter | 0.084 in (2.1 mm) |
| Color Code | Light Blue, Brown, Green/Yellow |
Outer Jacket
| Separator | Paper Tape |
|---|---|
| Material | PVC - Polyvinyl Chloride |
| Nom. Thickness | 0.034 in (0.86 mm) |
| Nom. Diameter | 0.253 in (6.43 mm) |
Electrical Characteristics
Electricals
| Element | Conductor(s) |
|---|---|
| Nom. Conductor DCR | 6.66 Ohm/1000ft |
| Max. Current | 7 Amps per conductor @ 30°C |
Voltage
| UL Voltage Rating | (Type SVT) |
|---|
Mechanical Characteristics
| Max. Pull Tension | 61.5 lbs (27.9 kg) |
|---|---|
| Bulk Cable Weight | 39 lbs/1000ft |
Temperature
| UL Temperature | 60°C |
|---|---|
| Operating | -20°C to +60°C |
Bend Radius
| Stationary Min. | 2.5 in (64 mm) |
|---|---|
| Installation Min. | 2.5 in (64 mm) |
Standards and Compliance
| NEC / UL Compliance | SVT |
|---|---|
| AWM Compliance | SVT |
| European Directive Compliance | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC Compliance | China RoHS II (GB/T 26572-2011) |
History
| Update and Revision | Revision Number: 0.525 Revision Date: 09-07-2025 |
|---|---|
| Footnote | F - MAY CONTAIN MORE THAN 1 PIECE. MINIMUM LENGTH OF ANY ONE PIECE IS 50'. |
