Portable Cordage, 3 C #14 Str BC, PVC Ins, PVC Jkt, UL Type SJT
Portable Cordage, 3 Conductor 14AWG (41x30) Bare Copper, PVC Insulation, PVC Outer Jacket, UL Type SJT
- Availability
- Global
- Status
- Active
- Orderable items
- 1
Part numbers
19364 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | Putup Type | Length | UPC | Footnote | Order |
|---|---|---|---|---|---|---|
| 19364 010250 | Black | Reel | 250 ft | 612825127017 | C | Order online |
Specifications
Product Overview
| Suitable Applications | Portable cordage for supplying power to appliances and tools |
|---|
Construction Details
| Overall Cable Diameter (Nominal) | 0.402 in (10.2 mm) |
|---|
Conductor
| Element | Conductor(s) |
|---|---|
| No. of Elements | 3 |
| Size | 14 AWG |
| Stranding | 41x30 |
| Material | BC - Bare Copper |
| Notes | 2.08mm2 |
Insulation
| Element | Conductor(s) |
|---|---|
| Material | PVC - Polyvinyl Chloride |
| Nom. Thickness | 0.033 in (0.84 mm) |
| Nom. Insulation Diameter | 0.141 in (3.58 mm) |
| Color Code | Light Blue, Brown, Green/Yellow |
Outer Shield
| Shield Type | Tape |
|---|---|
| Material | Bi-Laminate (Alum+Poly) |
| Coverage | 100% |
| Drainwire Type | 20 AWG (7x28) TC |
Outer Jacket
| Material | PVC - Polyvinyl Chloride |
|---|---|
| Nom. Thickness | 0.042 in (1.1 mm) |
| Nom. Diameter | 0.402 in (10.2 mm) |
Electrical Characteristics
| Nom Outer Shield DCR | 7.37 Ohm/1000ft (24.2 Ohm/km) |
|---|
Electricals
| Element | Conductor(s) |
|---|---|
| Nom. Conductor DCR | 2.76 Ohm/1000ft |
| Max. Current | 15 Amps per conductor @ 30°C |
Voltage
| UL Voltage Rating | 300 V (Type SJT) |
|---|
Mechanical Characteristics
| Max. Pull Tension | 172.5 lbs (78.24 kg) |
|---|---|
| Bulk Cable Weight | 97 lbs/1000ft |
Temperature
| UL Temperature | 60°C |
|---|---|
| Operating | -20°C to +60°C |
Bend Radius
| Stationary Min. | 4.0 in (100 mm) |
|---|---|
| Installation Min. | 4.0 in (100 mm) |
Standards and Compliance
| NEC / UL Compliance | SJT |
|---|---|
| AWM Compliance | SJT |
| European Directive Compliance | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC Compliance | China RoHS II (GB/T 26572-2011) |
History
| Update and Revision | Revision Number: 0.546 Revision Date: 09-07-2025 |
|---|---|
| Footnote | C - CRATE REEL PUT-UP. |
