Product Number: 19227

Portable Cordage, 2 C #18 Str BC, EPDM Ins, CPE Jkt, UL Type SJO

Name: Belden 19227
Brand: Belden
SKU: 19227

Portable Cordage, 2 Conductor 18AWG (16x30) Bare Copper, EPDM Insulation, CPE Outer Jacket, UL Type SJO

Ships from and sold by A5 IT.

Part numbers

19227 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #	Color	Putup Type	Length	UPC	Footnote	Order
19227 010250	Black	Reel	250 ft	612825126850	C F	Order online

Overall Cable Diameter (Nominal)	0.29 in

Element	Conductor(s)
Material	EPDM - Ethylene Propylene Diene Monomer
Nom. Thickness	0.031 in (0.79 mm)
Nom. Insulation Diameter	0.110 in (2.79 mm)
Color Code	Black, White

Material	No Shield

Separator	Paper Tape
Material	CPE - Chlorinated Polyethylene (Thermoset)
Nom. Thickness	0.035 in (0.89 mm)
Nom. Diameter	0.29 in

Nom. Conductor DCR	6.97 Ohm/1000ft
Max. Current	10 Amps per Conductor at 25oC (7 Amps over 50 ft)

UL Voltage Rating	300 V

Max. Pull Tension	41.6 lbs (18.9 kg)
Bulk Cable Weight	44 lbs/1000ft

UL Temperature	90°C
Operating	-20°C To +90°C

Stationary Min.	2.9 in (74 mm)
Installation Min.	2.9 in

Environmental Suitability	Indoor, Oil Resistance
NEC / UL Compliance	Article 400, SJO
AWM Compliance	SJO
CEC / C(UL) Compliance	LL7874.
European Directive Compliance	EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
APAC Compliance	China RoHS II (GB/T 26572-2011)

Update and Revision	Revision Number: 0.384 Revision Date: 09-07-2025
Footnote	C - CRATE REEL PUT-UP., F - MAY CONTAIN MORE THAN 1 PIECE. MINIMUM LENGTH OF ANY ONE PIECE IS 50'.
