EDAP52xx - Series
Regular Shelf with perforation 19" for E-Series. The depth of mounting is adjustable. Mounted on each corner to the frame for maximum stability.
- Availability
- EMEA
- Status
- Active
- Orderable items
- 18
Part numbers
SHELF REGULAR E-SERIES is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Depth | Load Capacity | Application | Color | Order |
|---|---|---|---|---|---|
| EDAP5211 | 150 mm | 15 kg | E-Series Cabinets | Gray | Order online |
| EDAP5212 | 150 mm | 15 kg | E-Series Cabinets | Black | Order online |
| EDAP5221 | 250 mm | 20 kg | E-Series Cabinets | Gray | Order online |
| EDAP5222 | 250 mm | 20 kg | E-Series Cabinets | Black | Order online |
| EDAP5231 | 350 mm | 40 kg | E-Series Cabinets | Gray | Order online |
| EDAP5232 | 350 mm | 40 kg | E-Series Cabinets | Black | Order online |
| EDAP5241 | 450 mm | 40 kg | E-Series Cabinets | Gray | Order online |
| EDAP5242 | 450 mm | 40 kg | E-Series Cabinets | Black | Order online |
| EDAP5251 | 550 mm | 40 kg | E-Series Cabinets | Gray | Order online |
| EDAP5252 | 550 mm | 40 kg | E-Series Cabinets | Black | Order online |
| EDAP5261 | 650 mm | 40 kg | E-Series Cabinets | Gray | Order online |
| EDAP5262 | 650 mm | 40 kg | E-Series Cabinets | Black | Order online |
| EDAP5271 | 750 mm | 40 kg | E-Series Cabinets | Gray | Order online |
| EDAP5272 | 750 mm | 40 kg | E-Series Cabinets | Black | Order online |
| EDAP5281 | 850 mm | 40 kg | E-Series Cabinets | Gray | Order online |
| EDAP5282 | 850 mm | 40 kg | E-Series Cabinets | Black | Order online |
| EDAP5291 | 950 mm | 40 kg | E-Series Cabinets | Gray | Order online |
| EDAP5292 | 950 mm | 40 kg | E-Series Cabinets | Black | Order online |
Specifications
Application
| Environmental Space | Indoor |
|---|
Mechanical Characteristics
| Load Capacity - Static | 40 kg |
|---|
Environmental and Overall Characteristics
| Finish | Powder Coated |
|---|---|
| Material | Steel |
Standards
| EU Directive 2011/65/EU (RoHS 2) | Yes |
|---|---|
| MII Order #39 (China RoHS) | EUP 50 |
Related Part Numbers
| Included Parts | Shelf, 4x or 8x sets of Screw M6, Plastic washer, Captive nut M6 |
|---|---|
| Packaging | Individually packed. |
| Update and Revision | Revision Number: 0.64 Revision Date: 10-04-2023 |
