Product Number: FRCE3YN3U

Fiber Raceway Elbow, 4x4, 30 Degree Up

Fiber Raceway Elbow, 4x4, 30 Degree Up, without Lid, Yellow

Availability: EMEA | Americas
Status: Active
Orderable items: 1

Ships from and sold by A5 IT.

Part numbers

FRCE3YN3U is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #	Color	Length	Order
FRCE3YN3U	Yellow	4.173 in	Order online

Specifications

Product Overview

Environmental Space	Indoor

Construction

Weight	0.551 lbs
Overall Height	4.330 in (109.982 mm
Overall Width	4.842 in
Overall Length	4.173 in

Mechanical Characteristics

Mechanical Tests

Description

Product Material

Materials

Material	Fire retardant plastic, Halogen free, UL94-VO rated

Product Notes

Notes

The 30-degree up elbow is a 100-mm vertical lead off with an internal lid, so that new optical fibre cords can be installed within the elbow and existing optical fibre cords removed, where necessary. This is usually used where cords may be already installed and either an angular duct feed off or an alignment adjustment is needed. There are two 100-mm outlets which use either: standard joiners or slotless joiners that are available separately. The 30-degree up elbow is a 100-mm vertical lead off with an internal lid, so that new optical fibre cords can be installed within the elbow and existing optical fibre cords removed, where necessary. This is usually used where cords may be already installed and either an angular duct feed off or an alignment adjustment is needed. There are two 100-mm outlets which use either: standard joiners or slotless joiners that are available separately.
