Product Number: D4K-12TP-RJ45

DRAGON MACH4x00 media module with 12 x FE/GE TX ports; field-replaceable

Name: Belden D4K-12TP-RJ45
Brand: Hirschmann
SKU: D4K-12TP-RJ45

Ships from and sold by A5 IT.

Part numbers

D4K-12TP-RJ45 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #	Type	Order
942155001	D4K-12TP-RJ45, Linecard	Order online

Type	D4K-12TP-RJ45
Name	D4K-12TP-RJ45
Description	DRAGON MACH4x00 media module with 12 x FE/GE TX ports; field-replaceable
Port Type and Quantity	12 x 10/100/1000 Mbit/s RJ45 sockets für TP cable, auto-crossing, auto-negotiation, auto-polarity

Operating Voltage	power supply via the backplane of the switch
Power Consumption	15 W

Diagnostics	LEDs (power, link status, data)

MTBF (Telcordia SR-332 Issue 3) @ 25°C	2 921 848 h
Operating temperature	0-+60 °C
Minimum Storage Temperature	-40-+70 °C
Relative humidity (non-condensing)	10-95 %
Protective paint on PCB	Yes (conformal coating)
Dimensions (WxHxD)	220 mm x 334 mm x 23 mm
Weight	0.65 kg
Mount Type	Plug-in device

Safety of industrial control equipment	cUL61010-1/-2-201, EN60950-1

Guarantee	60 months (please refer to the " https://assets.belden.com/m/1424ddb7a3280e7a/original/Hirschmann-Automation-and-Control-GmbH-Terms-of-Guarantee.pdf ">"terms of guarantee or detailed information)
