| MAC address management | Sticky MAC learning; VLAN and global MAC address; static MAC; MAC address removal alert |
| VLAN | Support 4K VLAN; VLAN based on port/MAC/IP/protocol port number; VLAN Mapping N:1; PVLAN; Super-VLAN; GVRP |
| QinQ | Q-in-Q and flexible Q-in-Q |
| Redundancy | STP/MSTP/RSTP; BPDU Guard; Root Guard; Flap Guard、Loop Guard; portfast test; BPDU message encryption; VIST; LBD; EIPS |
| Port mirroring | N:1 port mirroring; data flow mirroring; RSPAN; ERSPAN; VLAN mirroring; |
| Link aggregation | Static aggregation, LACP (802.3ad) and PaGP |
| Router Feature | IPv4 protocol | TCP; UDP; Ping; TraceRoute; Telnet; FTP; TFTP; ICMPv4; DNS; UDP Helper; DHCP; DHCP server; DHCP Delay; DHCP Snooping; NTP; SNTP; support ARP and ARP Proxy |
| IPv6 protocol | IPv4/IPv6 dual stack; TCP6; UDP6; RawIP6; Ping v6; TraceRoute6; Telnet6; FTPv6; TFTPv6; DNSv6; ICMPv6; VRRPv3; DHCPv6; ND; PMTUD |
| IPv4 router protocol | Static route; RIPv1/v2; RIP; OSPF; IS-IS; BGP; GRE; IPIP tunnel; ECMP; Network load balancing |
| IPv6 router protocol | IPv6 static route; RIPng; OSPFv3; IS-ISV6; BGPv4+; IPV6 transition tunnel; GREv6 |
| Multicast | Layer2 multicast | IGMPv1/v2/v3 Snooping; multicast VLAN; support MLD v1/v2 Snooping |
| Layer3 multicast | IGMPv1/v2/v3; MLD v1/v2; multicast static router; IPv4 intra-domain multicast router; IPv4 inter-domain multicast router; IPv4 multicast
management; support MSDP/PIM-SM/PIM-DM/PIM-SSM/PIM-SDM; IPv6 intra-domain multicast router; IPv6 inter-domain multicast router; IPv6 multicast management; IPv6 multicast forwarding; MSDP for IPv6; support PIM-SMv6 and PIM-SSMv6 |
| MPLS | MPLS | LDP; MPLS L3VPN |
| ACL/QOS | ACL | IPv4/IPv6 standard ACL; IPv4/IPv6 extended ACL; mixed ACL; MAC ACL; ACL based on port; ACL based on layer3 interface; ACL based on VLAN; global ACL; Ingress/Egress ACL; ACL matching log; time-based ACL |
| QOS | Scheduling; 802.1p and DSCP priority mapping; traffic classification; traffic policing; traffic shaping; congestion management; congestion avoidance; speed limitation based on time domain; traffic policing based on time domain |
| Security function | Network security | Message validity test; URPF; ACL; port isolation; DHCP Snooping; DHCPv6 Snooping; IPSG; IPSGv6; AARF; Dynamic ARP Inspection; ARP Check; Host Guard; BPDU message encryption |
| Access security | Portal certification; 802.1X certification; MAC certification; port security |
| Data center feature | VXLAN | VXLAN cross data center interconnection; VTEP; EVPN |
| TRILL | TRILL transparent exchange network |
| SDN | OpenFlow1.1/1.2/1.3; XML API/NETCONF; M-LAG |
| Device Maintenance | Device management method | Console; Telnet; SSH v1/v2 |
| File management | FTP/TFTP upload/download files; formatting files; creating catalog; file management |
| Network maintenance | Ping; TraceRoute; LSP Ping/Tracert function; interface loop monitoring |
| Network management | SNMP v1/v2/v3; RMON; webmaster; SSH v1/v2; IPFIX/SFLOW |
| OAM function | 802.3ah OAM; 802.1ag OAM; ITU Y.1731 OAM |
| Energy saving | IEEE 802.3az EEE |
| Reliability | Device reliability | All modules support hot-plugging; real-time backup data; support ISSU; support IOS backup and recovery; support configuration file backup and recovery |
| Network reliability | VRRP; VBRP; VRRPv3; BFDv6; BFD for VRRP/BGP/IS-IS/RIP/OSPF/static router; support VRRP and TRILL linkage; ULFD; ULPP; Monitor Link |
| Stacking | | Stackable, up to 2 devices in one stack |
