Industrial, fanless Fast/Gigabit PoE Injector, PoE/PoE+ (IEEE 802.3at), 30W (25.5W at load) per port
The RPI-A1-4PoE is a DIN-rail mountable single-phase-input power supply, which provides power for Power over Ethernet (PoE and PoE+) applications. It injects power to 4 individual PoE channels (IEEE 802.3at) via RJ45 Ethernet ports to supply powered devices (PD) of type 1 and type 2.
- Availability
- Global
- Status
- Active
Specifications
Product description
| Port Type and Quantity | 4 x 10/100/1000 BASE-TX ports |
|---|
Product Life Cycle
| Last Order Date | 2025-09-30 |
|---|---|
| Last Delivery Date | 2025-12-31 |
Power requirements
| Operating Voltage | 110 - 150 VDC and 100 - 240 VAC |
|---|---|
| Power Consumption | 160 W |
Ambient conditions
| MTBF | 137 years (48V/2.7A) (according SN29500, IEC61709) |
|---|---|
| Operating temperature | -25-+60 °C |
| Relative humidity (non-condensing) | 5-95 % |
| Dimensions (WxHxD) | 77mm x 128 mm x 177 mm |
| Weight | 850 g |
| IP Protection Rating | IP20 |
Approvals
| Safety of industrial control equipment | EN60950-1, EN 61131-2 , cUL60950-1 (pending) |
|---|---|
| Transportation | EN50121-4 |
Reliability
| Guarantee | 24 months (please refer to the <a href=" https://assets.belden.com/m/1424ddb7a3280e7a/original/Hirschmann-Automation-and-Control-GmbH-Terms-of-Guarantee.pdf " terms of guarantee </a for detailed information) |
|---|
Further Instructions
| Product Documentation | https://www.doc.hirschmann.com |
|---|---|
| Certificates | https://www.doc.hirschmann.com/certificates.html |
History
| Update and Revision | Revision Number: 0.70 Revision Date: 11-27-2025 |
|---|
