T-Splitter, Sensor/Actuator, double M12 3 pole female, with Black PUR cable
T-Splitter, Sensor/Actuator, M12 to M12, IP67, PUR orange body, 3-pin M12 Female to 3-pin M12 female, 63 V, 4 A, with PUR, black jacket, 4x0.34mm2 cable
- Availability
- Global
- Status
- Active
- Orderable items
- 6
Part numbers
ZV 2 4-3-225 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Item Description | Cable Length | Order |
|---|---|---|---|
| 600003176 | ZV 2 4-3-225/10 M | 10 m | Order online |
| 600003178 | ZV 2 4-3-225/5 M | 5 m | Order online |
| 23368 | ZV 2 4-3-225/15 M | 15 m | Order online |
| 43780 | ZV 2 4-3-225/10 M | 10 m | Order online |
| 43782 | ZV 2 4-3-225/2 M | 2 m | Order online |
| 43783 | ZV 2 4-3-225/5 M | 5 m | Order online |
Specifications
Face View Side 1
| Product Family | Sensor / Actuator Connectors |
|---|---|
| Connector Type | T-Splitter |
| Shielding Type | Unshielded |
| Voltage Rating | 63 V |
| Rated Impulse Voltage | 1.5 kV |
| Operating Voltage | 50 V AC / 60 V DC |
| Current Rating | 4 A |
Technical Data Side 1
| Side 1 Product Sub Family | M12 Standard |
|---|---|
| Side 1 Type of Contact/Gender | 2 x Female |
| Connector Design | T Body |
| Attachment Type | Coupling Nut |
| Number of Pins | 4 |
| Coding, Side 1 | A |
| Side 1 Contact Resistance | ≤ 5 mOhm |
| Insulation Resistance | ˃ 10^9 Ohm |
| Mating Cycles | ≤ 100 |
| Ambient Temperature (Operation)* | - 25 °C - + 80 °C |
| Protection Degree / IP Rating** | IP65, IP67 |
| Side 1 Design Standard | IEC 61076-2-101 |
| Side 1 Pollution Degree | 3 acc. to DIN EN 60664-1 (VDE 0110-1) |
| Overvoltage Category | III acc. to DIN EN 60664-1 (VDE 0110-1) |
| Contact Base Material | CuSn |
| Side 1 Contact Plating | Cu/Au |
| Contact Bearer Material | TPU |
| Contact Bearer Color | Black |
| Flammability Class (Contact Bearer) | UL 94 HB |
| Molded Body Material | TPU |
| Molded Body Color | Orange |
| Flammability Class (Molded Body) | UL 94 HB |
| Attachment Material | CuZn |
| Attachment Plating | 1xNickel-plated, 1xNylon Black coated |
| O-Ring Material | FKM, green |
| Fastening Torque (Attachment) | M 12x1: (50-60) Ncm, hand-tight |
Cable Data
| Cable Number | 225 |
|---|---|
| Conductor Size | 0.34 mm2 |
| Number of Wires | 4 |
| Minimal Bending Radius (Fixed Inst) | 5 x D |
| Minimal Bending Radius (Flexible Inst) | 10 x D |
| Cycles (Bending) | 5 M |
| Cycles (Torsion) | ˃ 3 M @ ± 360 °/1 m |
| Conductor Material | Cu |
| Cable Jacket Material | PUR |
| Cable Jacket Color | black matt similarly RAL 9005 |
| Cable Diameter D | ø 4.70 ± 0.15 mm |
| Wire Insulation Material | PP |
| Insulated Wire Diameter | ø 1.30 ± 0.15 mm |
| Ambient Temperature (Fixed Installation) | - 50 °C - + 90 °C (UL: + 80 °C) |
| Ambient Temperature (Flex Installation) | - 25 °C - + 90 °C (UL: + 80 °C) |
| Ambient Temperature (Drag Chain Inst) | - 25 °C - + 60 °C |
| UL Cable Type | AWM: 20549 |
| Flammability Class (Cable Jacket) | DIN EN 60332-2-2, VDE 0482-332-2-2, IEC 60332-2-2, CSA FT-2 |
| Cable Characteristics | Good microbes and hydrolysis resistance; Mainly plasticizer diffusion free; Exclusion of PVC and silicone; Coldness flexibility; Free of lacquer wetting disturbing substances |
Safety & Environmental Compliance
| RoHS Compliant | Yes |
|---|
Resistances
| Halogenfree | Yes |
|---|---|
| Oil Resistance | Yes |
Notes
| Note Derating | Notice derating |
|---|
