FX Brilliance OS2 LC Connector
FX Brilliance Universal LC Field Installable Connector, Single-mode, OS2, Blue Housing, 1/Pack, with support for 250 um (using Breakout kit), 900 um, 2 mm and 3 mm fiber (using jacketed boots). Includes 900 um boot, other accessories (Breakout Kit & jacketed boots) sold separately.
- Availability
- Global
- Status
- Active
- Orderable items
- 1
Part numbers
AX105203-S1 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | Packaging | UPC | Order |
|---|---|---|---|---|
| AX105203-S1 | Blue | 1-Pack | 611589105217 | Order online |
Specifications
Product Overview
| Environmental Space | Indoor |
|---|---|
| Suitable Applications | Field-termination of fiber optic cables within Patch Panels, Distribution Frames, Workstation Outlets for FTTD (Fiber to the Desk), drops for FTTH (Fiber to the home) and MDU (Multiple Dwelling Units). |
Construction
| Weight | 0.003 kg |
|---|
Fiber Cable Construction
| Fiber Type | OS2 |
|---|
Inner Jacket
| Inner Jacket | Inner Jacket |
|---|
Mechanical Characteristics
| Maximum Insertion Loss | 0.50 dB |
|---|---|
| Typical Insertion Loss | 0.30 dB |
| Minimum Reflectance @ 1550nm | -50 dB |
| Termination Style | Mechanical |
| Durabilities@Termination1 | 500 cycles, less than 0.2 dB change, FOTP-21 |
Mechanical Specifications
| Test | GR-326-CORE/1081-CORE (SM) |
|---|---|
| Intermateability Requirement | Compliant with TIA/EIA-604-3 (FOCIS 3) |
| Operating Temp Range | -40°C to +75°C |
| Storage Temp Range | -40°C to +60°C |
| Durability | 500 cycles, less than 0.2 dB change, FOTP-21 |
Mechanical Tests
| Description |
|---|
Temperature Range
| Operating Temperature Range | -40°C to +75°C |
|---|---|
| Storage Temperature Range | -40°C to +60°C |
Product Material
Materials
| Description | Material | Color |
|---|---|---|
| Boot | Rubber | Black |
| Protective Ferrule Cap | Plastic | Opaque |
| Connector Body | Plastic | Blue |
| Ferrule | Ceramic |
Standards
| TIA/EIA Compliance | TIA 568-C.3 |
|---|---|
| MII Order #39 (China RoHS) | EUP 50 |
| Safety Listing | ACA |
Related Part Numbers
| Included Parts | 900 μm boot, protective ferrule cap |
|---|---|
| Related Parts | FX Brilliance Precision Installation Kit, Boots for 2mm and 3mm Jacketed Fiber, 250μm to 900μm break out kits. |
| Packaging | Individually packaged in a sealed plastic bag. |
Product Notes
| Notes | Refer to Installation Guide PX105234 for installation procedures. Fiber can be reterminated up to 5 times with the same connector |
|---|
History
| Update and Revision | Revision Number: 0.9 Revision Date: 03-30-2026 |
|---|
