Product Number: FT3LC9SHFS01

FX Fusion Splice-On Connector, OM3-4, LC Simplex, 900μm Tight Buffer, Short Boot

Name: Belden FT3LC9SHFS01
Brand: Belden
SKU: FT3LC9SHFS01

FX Fusion Splice-On Connector, OM3-4, LC Simplex, 900μm Tight Buffer, Short Boot, Aqua Housing

Ships from and sold by A5 IT.

Specifications

Environmental Space	Indoor/Outdoor
Suitable Applications	Field-termination of fiber optic cables within Patch Panels, Distribution Frames, Workstation Outlets for FTTD (Fiber to the Desk), drops for FTTH (Fiber to the home) and MDU (Multiple Dwelling Units).

Weight	0.021 lbs
Overall Length	47.18 mm

Fiber Type	OM3

Inner Jacket	Inner Jacket

Test	TIA 568.3-D (MM)

Description

Description	Material	Color
Boot	Rubber	Black
Protective Ferrule Cap	Plastic	White
Connector Front Housing	Plastic	Aqua
Connector Rear Housing	Nickel plated zinc alloy diecast	Metal
Ferrule	Zirconia-Ceramic	White

TIA/EIA Compliance	TIA 568.3
MII Order #39 (China RoHS)	EUP 50

Included Parts	900 μm short boot, protective ferrule cap, splice protection sleeve
Related Parts	FX Pigtails.

Packaging	Single Pack
Notes	This connector is compatible with all patch panel termination methods, including adapter frames and splice cassettes. For workstation outlet applications, ensure there is adequate space to maintain the minimum bend radius of the fiber. This product is not compatible with KeyConnect Side-Entry Boxes (AX104132 & AX104133). For more information, please contact Belden Technical Support.
