FiberExpress Ultra Splice Tray 8 inches
FiberExpress Ultra Splice Tray 8 inches
- Availability
- Global
- Status
- Active
Specifications
Product Overview
| Environmental Space | Indoor |
|---|---|
| Suitable Applications | FiberExpress Solutions, Backbone, Telecommunications Room, Main Distribution Room, Data Centers |
Construction
| Weight | 0.700 lbs |
|---|---|
| Overall Height | 0.550 in |
| Overall Width | 4.50 in |
| Overall Length | 8.0 in |
Physical Specifications
| Max Capacity | 24 F |
|---|
Inner Jacket
| Inner Jacket | Inner Jacket |
|---|
Mechanical Characteristics
Mechanical Tests
| Description |
|---|
Temperature Range
| Operating Temperature Range | -10°C To +60°C |
|---|---|
| Storage Temperature Range | -10°C To +60°C |
Product Material
Materials
| Description | Material | Color |
|---|---|---|
| Splice Tray | Aluminum | Black |
| Splice Holder | Polypropylene | Gray |
| Cover | Plastic | Clear |
Standards
| MII Order #39 (China RoHS) | EUP 50 |
|---|
Related Part Numbers
| Included Parts | 1 x Splice Tray with Adhesive Holder, 1x Splice Tray Cover |
|---|
Product Notes
| Packaging | Individually packaged in a plastic bag. |
|---|---|
| Notes | For more information, please refer to our web site at http://www.belden.com . |
History
| Update and Revision | Revision Number: 0.257 Revision Date: 10-23-2025 |
|---|
