MachFlexTM Robotic Multi-Pair Control, 2 Pr 23 AWG Str TC, ETFE Ins, PVC Outer Jkt
MachFlexTM Robotic Multi-Pair Control & Signal Cable, 2 Pair 23 AWG Stranded Tinned Copper, ETFE Insulation, PVC Outer Jacket
- Availability
- EMEA | Asia Pacific
- Status
- Active
- Orderable items
- 6
Part numbers
MRTA2P23U is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | Length | Order |
|---|---|---|---|
| MRTA2P23U G8U100M | Gray | 100 m | Order online |
| MRTA2P23U G8U200M | Gray | 200 m | Order online |
| MRTA2P23U G8U300M | Gray | 300 m | Order online |
| MRTA2P23U 003100M | Orange | 100 m | Order online |
| MRTA2P23U 003200M | Orange | 200 m | Order online |
| MRTA2P23U 003300M | Orange | 300 m | Order online |
Specifications
Product Overview
| Suitable Applications | MachFlex Robotic AWM 20276, Multi-Pair Cables are meeting the high demands of the robotic industry on the cabling of continuous moving machinery and the corresponding robotic components. These cables are specially designed for high mechanical requirements, they can withstand highly dynamic bending and torsional movements, and can be used in crucial industrial environments |
|---|
Construction Details
| Overall Cable Diameter (Nominal) | 4.2 mm (0.17 in) |
|---|
Conductor
| Element | Pair(s) |
|---|---|
| No. of Elements | 2 |
| Size | 23 AWG |
| Stranding | Stranded |
| Material | TC - Tinned Copper |
Insulation
| Material | ETFE - Ethylene Tetrafluoroethylene |
|---|---|
| Color Code | 1. Black&Brown, 2. Black&Red |
Outer Jacket
| Material | PVC - Polyvinyl Chloride |
|---|
Electrical Characteristics
Electricals
| Max. Conductor DCR | 74.5 Ohm/km |
|---|
Voltage
| UL Voltage Rating | 30 V (Max. Operating Voltage) |
|---|
Mechanical Characteristics
| Bend Radius Table Notes | ±90o Bending: Min. 8 million cycles (Speed: 60 cycles/min.; Bending radius: 7.5D); Drag Chain: Min. 25 million cycles (Traversing distance: 350mm; Speed: 70 cycles/min; Bending radius: 6D); Vertical Torsion Test +/-1800/m: Min. 8 million cycles; Horizontal Torsion Test +/-900/m: Min. 8 million cycles. |
|---|---|
| Bulk Cable Weight | 27 kg/km (18 lbs/1000ft) |
Temperature
| Operating | -30°C to +80°C |
|---|
Standards and Compliance
| Environmental Suitability | Indoor Outdoor, Indoor, Outdoor, Oil Resistance |
|---|---|
| Flammability / Reaction to Fire | FT1, VW-1, IEC 60332-1-2 |
| AWM Compliance | AWM 20276 |
| CEC / C(UL) Compliance | CSA C22.2 No.210. |
| European Directive Compliance | EU Directive 2011/65/EU (RoHS 2) |
| APAC Compliance | China RoHS II (GB/T 26572-2011) |
Product Notes
| Notes | Suitability -Oil Resistant : IRM 902 120°Cx18hrs, IRM 903 120°Cx18hrs |
|---|
History
| Update and Revision | Revision Number: 0.41 Revision Date: 02-03-2026 |
|---|
