Product Number: FDSR024F2

Indoor/Outdoor Flexible Ribbon OS2 24 Fibers OFCR Aluminum Interlocked Armor Sub-Units 3.0mm (12F)

Name: Belden FDSR024F2
Brand: Belden
SKU: FDSR024F2

FX Indoor/Outdoor, Flexible Ribbon, OS2, 24 Fibers, OFCR, Aluminum Interlocked Armor, Subunits 3.0mm (12F), Black Jacket

Ships from and sold by A5 IT.

Part numbers

FDSR024F2 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #	Color	Putup Type	Order
FDSR024F2	Black	Reel	Order online

Product Category	Fiber Ribbon Cable
Suitable Applications	Data Center, RAN, Horizontal Backbone, Premise Backbone

Number of Active Subunits	2
Number of Fillers	2
Fibers Per Subunit	12
Subunit Diameter	0.118 in (3.0 mm)
Subunit Color	Yellow
Fiber SubUnit Strength Members	Aramid yarns
Central Strength Member Type	GRP

Inner Jacket Strength Member	Aramid Yarns
Material	PVC - Polyvinyl Chloride
Nominal Diameter@InnerJacket1 (cnv)	0.38 in (9.6 mm)
Color	Black
Number of Inner Jacket Ripcords	1

Armor Type and Material	AIA - Aluminum Interlock Armor

Wavelength	1310 nm	1550 nm
Max. Attenuation	0.40 dB/km	0.30 dB/km
10 Gigabit Ethernet Performance	10,000 m	50,000 m

Minimum Bend Radius During Installation	20x Cable OD
Minimum Bend Radius During Operation	10x Cable OD
Max. Tensile Strength During Installation	1320 N (300 lbf)
Max. Tensile Strength During Operation	400 N (90 lbf)
Crush Resistance	440 N/cm
Bulk Cable Weight	160 lbs/kft (238 kg/km)

Installation Temperature Range	-10°C to +60°C
Operating Temperature Range	-40°C to +70°C
Storage Temperature Range	-40°C to +70°C

Environmental Suitability	Indoor/Outdoor, Sunlight Resistance
Flammability / Reaction to Fire	UL 1666, UL 1685, FT4
NEC / UL Compliance	OFCR
CEC / C(UL) Compliance	OFCR.
ICEA Compliance	S-104-696
TIA/EIA Compliance	598-D
European Directive Compliance	EU Directive 2015/863/EU (RoHS 2 amendment)
