TT-SLD-006-LSNN

Product Number: TT-SLD-006-LSNN

Transit Grade Indoor/Outdoor Multi-Loose-Tube OS2 6 Fibers Dry Tubes 2.5mm Corrugated Steel Tape Single Jacket

Transit Grade, Indoor/Outdoor, Multi-Loose-Tube, OS2, 6 Fibers, Dry Tubes 2.5mm, Corrugated Steel Tape, Single Jacket, Black, LSZH, OFCR-ST1

Availability
Global
Status
Active
Orderable items
1
Request a quoteOrder options (1)

Ships from and sold by A5 IT.

Part numbers

TT-SLD-006-LSNN is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #ColorPutup TypeOrder
TT-SLD-006-LSNNBlackReelOrder online

Specifications

Product Overview

Product CategoryFiber Multi-Loose Tube Cable
Suitable ApplicationsExtended Distance Horizontal & Backbone Data/Telco Network, Noisy Environment, Indoor/ Outdoor & Wet Locations, Armored, UV Resistant

Fiber Specifications

Fiber TypeOS2, G.657.A1, G.652.D
Fiber Diameter250 μm
Fiber Count6
Fiber Color CodingTIA-598-D

Cable Construction

Number of Active Subunits1
Number of Fillers4
Fibers Per Subunit6
Subunit WaterblockingGel Free
Subunit Diameter0.098 in (2.5 mm)
Subunit ColorTIA-598-D
Central Strength Member TypeGRP
Core Wrap MaterialWater Block Tape

Armor Specifications

Armor Type and MaterialCST - Corrugated Steel Tape

Outer Jacket Specifications

Strength MemberFiberglass Yarns
Jacket MaterialLSZH - Low Smoke Zero Halogen (Flame Retardant)
Nom. Diameter0.530 in (13.5 mm)
Outer Jacket ColorBlack
Outer Jacket Ripcord2

Optical Characteristics

Wavelength1310 nm1550 nm
Max. Attenuation0.35 dB/km0.25 dB/km
10 Gigabit Ethernet Performance10,000 m50,000 m
40 Gigabit Ethernet Performance10,000 m--
100 Gigabit Ethernet Performance10,000 m--

Mechanical Characteristics

Minimum Bend Radius During Installation20 x Cable OD
Minimum Bend Radius During Operation10x Cable OD
Max. Tensile Strength During Installation2670 N (600 lbf)
Max. Tensile Strength During Operation800N (180lbf)
Crush Resistance220 N/cm
Bulk Cable Weight130 lbs/kft (193 kg/km)

Temperature Range

Installation Temperature Range-10°C to +60°C
Operating Temperature Range-40°C to +70°C
Storage Temperature Range-40°C to +70°C

Standards and Compliance

Environmental SuitabilityIndoor/Outdoor, Sunlight Resistance, Burial
Flammability / Reaction to FireUL1666, UL 1685
NEC / UL ComplianceOFCR-ST1
CEC / C(UL) ComplianceFT4.
ICEA ComplianceS-104-696
TIA/EIA Compliance568.3, 598-D
European Directive ComplianceEU Directive 2015/863/EU (RoHS 2 amendment)

History

Update and RevisionRevision Number: 0.4 Revision Date: 05-07-2026
