TR-3LD-024-NSUN

Product Number: TR-3LD-024-NSUN

Outdoor (OSP) Multi-Loose-Tube OM3 24 Fibers Dry Tubes 2.5mm Corrugated Steel Tape Single Jacket

Renewable Grade, Outdoor (OSP), Multi-Loose-Tube, OM3, 24 Fibers, Dry Tubes 2.5mm, Corrugated Steel Tape, Single Jacket, Black, UV Resistant

Availability
Global
Status
Active
Orderable items
1
Request a quoteOrder options (1)

Ships from and sold by A5 IT.

Part numbers

TR-3LD-024-NSUN is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #ColorPutup TypeOrder
TR-3LD-024-NSUNBlackReelOrder online

Specifications

Product Overview

Product CategoryFiber Multi-Loose Tube Cable
Suitable ApplicationsExtended Distance Horizontal & Backbone Data/Telco Network, Noisy Environment, OSP, Outdoor & Wet Locations, Rodent Resistant, UV Resistant

Fiber Specifications

Fiber TypeOM3
Fiber Core Diameter50/125 μm
Fiber Diameter250 μm
Fiber Count24
Fiber Color CodingTIA-598-D

Cable Construction

Number of Active Subunits2
Number of Fillers3
Fibers Per Subunit12
Subunit WaterblockingGel Free
Subunit Diameter0.098 in (2.5 mm)
Subunit ColorTIA-598-D
Central Strength Member TypeGRP
Cable Core Water BlockingWaterblock Tape

Armor Specifications

Armor Type and MaterialCST - Corrugated Steel Tape

Outer Jacket Specifications

Strength MemberFiberglass Yarns
Jacket MaterialPE - Polyethylene
Nom. Diameter0.520 in (13.2 mm)
Outer Jacket ColorBlack
Outer Jacket Ripcord2

Optical Characteristics

Wavelength850 nm1300 nm
Max. Attenuation3.0 dB/km1.0 dB/km
10 Gigabit Ethernet Performance400 m--
40 Gigabit Ethernet Performance100 m--
100 Gigabit Ethernet Performance70 m--
Min. Effective Modal Bandwidth (EMB)2000 MHz.km--
Min. Overfilled Launch (OFL) Bandwidth1500 MHz.km500 MHz.km

Mechanical Characteristics

Minimum Bend Radius During Installation20x Cable OD
Minimum Bend Radius During Operation10x Cable OD
Max. Tensile Strength During Installation2670 N (600 lbf)
Max. Tensile Strength During Operation800 N (180 lbf)
Crush Resistance220 N/cm
Bulk Cable Weight97 lbs/kft (144 kg/km)

Temperature Range

Installation Temperature Range-30°C to +60°C
Operating Temperature Range-40°C to +70°C
Storage Temperature Range-40°C to +70°C

Standards and Compliance

Environmental SuitabilityOutdoor, Sunlight Resistance, Burial
ICEA ComplianceS-87-640
TIA/EIA Compliance568.3, 598-D
Telcordia ComplianceTelcordia GR-20
European Directive ComplianceEU Directive 2015/863/EU (RoHS 2 amendment)

History

Update and RevisionRevision Number: 0.2 Revision Date: 01-12-2026
