Universal OFC MLT: Steel Central strength member, Gel filling loose tubes(4f/T), Gel filled core, WB Tape + LSZH Inner Jacket (black) + CST + LSZH Outer Jacket (black) 4F OS2
Universal (Indoor/Outdoor) Gel filling loose tubes(4f/T), Gel filled core optical fiber Multi Loose Tube cable with Water Blocking tape, Low Smoke Zero Halogen inner jacket (black), Corrugated Steel Tape armor and Low Smoke Zero Halogen outer jacket (black), 4F OS2, IEC 60332-3-24 Flame rating
- Availability
- Asia Pacific
- Status
- Active
Specifications
Product Overview
| Suitable Applications | For outdoor and indoor use in structured (data) wiring systems such as industrial backbone, campus backbone, building backbone (riser) and /or horizontal cabling. For outdoor and indoor use in networks for industrial, telecom, cable TV and/or broadcast. Easy to install in ducts, tunnels and trenches and /or tubes. Suitable for Direct Burial. |
|---|
Fiber Specifications
| Fiber Type | OS2, G.652.D |
|---|---|
| Fiber Core Diameter | 9 μm |
| Fiber Diameter | 125 μm |
| Fiber Buffer Material | PBT Polybutylene Terephthalate |
| Fiber Count | 4 |
| Fiber Color Coding | TIA-598-D |
Cable Construction
| Number of Active Subunits | 1 |
|---|---|
| Number of Fillers | 5 |
| Fibers Per Subunit | 4 |
| Subunit Waterblocking | Gel Filled |
| Subunit Color | Blue |
| Central Strength Member Type | Steel Rod |
Inner Jacket Specifications
| Material | LSZH - Low Smoke Zero Halogen (Flame Retardant) |
|---|---|
| Color | Black |
| Number of Inner Jacket Ripcords | 1 |
Armor Specifications
| Armor Type and Material | CST - Corrugated Steel Tape |
|---|
Outer Jacket Specifications
| Jacket Material | LSZH - Low Smoke Zero Halogen (Flame Retardant) |
|---|---|
| Nom. Diameter | 13.2 mm (0.520 in) |
| Outer Jacket Color | Black |
| Outer Jacket Ripcord | 1 |
Optical Characteristics
| Wavelength | 1310 nm | 1550 nm |
|---|---|---|
| Max. Attenuation | 0.36 dB/km | 0.22 dB/km |
| Mode Field Diameter | 9.2 μm | 10.4 μm |
Mechanical Characteristics
| Minimum Bend Radius During Installation | 330 mm |
|---|---|
| Minimum Bend Radius During Operation | 165 mm |
| Max. Tensile Strength During Installation | 3000 N (670 lbf) |
| Max. Tensile Strength During Operation | 1000 N (220 lbf) |
| Crush Resistance | 3000N/100mm |
| Bulk Cable Weight | 246 kg/km (165 lbs/1000ft) |
Temperature Range
| Operating Temperature Range | - 40°C to +70°C |
|---|---|
| Storage Temperature Range | - 40°C to +70°C |
Standards and Compliance
| Environmental Suitability | Indoor, Outdoor, Sunlight Resistance, UV Resistance, Burial |
|---|---|
| Flammability / Reaction to Fire | IEC 60332-3-24 |
| ISO/IEC Compliance | IEC 60793-1-1 IEC 60794-1-1 |
| European Directive Compliance | EU Directive 2011/65/EU (RoHS 2) |
History
| Update and Revision | Revision Number: 0.24 Revision Date: 12-07-2023 |
|---|
