FDSH0965D

Product Number: FDSH0965D

Indoor/Outdoor Heavy Duty Loose Tube OS2 96 Fibers OFCR Corrugated Steel Tape Armor Sub-Units (12F) Dry

FX Indoor/Outdoor, Heavy Duty Loose Tube, OS2, 96 Fibers, OFCR Corrugated Steel Tape Armor, Sub-Units (12F) Dry, Black Jacket

Availability
Global
Status
Active
Orderable items
1
Request a quoteOrder options (1)

Ships from and sold by A5 IT.

Part numbers

FDSH0965D is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #ColorPutup TypeOrder
FDSH0965DBlackReelOrder online

Specifications

Product Overview

Product CategoryFiber Multi-Loose Tube Cable
Suitable ApplicationsCampus Area Network, Long Haul, Backbone

Fiber Specifications

Fiber TypeOS2, G.657.A1, G.652.D
Fiber Diameter250 μm
Fiber Count96
Fiber Color CodingTIA-598-D

Cable Construction

Number of Active Subunits8
Fibers Per Subunit12
Subunit WaterblockingGel Free
Subunit Diameter0.098 in (2.5 mm)
Subunit ColorTIA-598-D
Central Strength Member TypeGRP
Core Wrap MaterialWater Block Tape

Inner Jacket Specifications

MaterialPVC - Polyvinyl Chloride
Nominal Diameter@InnerJacket1 (cnv)0.437 in (11.1 mm)
ColorBlack
Number of Inner Jacket Ripcords1

Armor Specifications

Armor Type and MaterialCST - Corrugated Steel Tape

Outer Jacket Specifications

Strength MemberFiberglass Yarns
Jacket MaterialPVC - Polyvinyl Chloride
Nom. Diameter0.680 in (17.3 mm)
Outer Jacket ColorBlack
Outer Jacket Ripcord2

Optical Characteristics

Wavelength1310 nm1550 nm
Max. Attenuation0.35 dB/km0.25 dB/km
10 Gigabit Ethernet Performance10,000 m50,000 m
40 Gigabit Ethernet Performance10,000 m--
100 Gigabit Ethernet Performance10,000 m--

Mechanical Characteristics

Minimum Bend Radius During Installation20 x Cable OD
Minimum Bend Radius During Operation10x Cable OD
Max. Tensile Strength During Installation2670 N (600 lbf)
Max. Tensile Strength During Operation800N (180lbf)
Crush Resistance440 N/cm
Bulk Cable Weight183 lbs/kft (272 kg/km)

Temperature Range

Installation Temperature Range-10°C to +60°C
Operating Temperature Range-40°C to +70°C
Storage Temperature Range-40°C to +70°C

Standards and Compliance

Environmental SuitabilityIndoor/Outdoor, Sunlight Resistance, Burial
Flammability / Reaction to FireUL 1666, UL 1685
NEC / UL ComplianceOFCR
CEC / C(UL) ComplianceFT4.
ICEA ComplianceS-104-696
TIA/EIA Compliance568.3, 598-D
European Directive ComplianceEU Directive 2015/863/EU (RoHS 2 amendment)

History

Update and RevisionRevision Number: 0.10 Revision Date: 05-05-2026
