Product Number: FIBM192AH

Indoor Mini-Distribution OS2 A2-B2 192 Fibers OFCP Aluminum Interlocked Armor Sub-Units 2.0mm (16F)

Name: Belden FIBM192AH
Brand: Belden
SKU: FIBM192AH

FX Indoor, Mini-Distribution, OS2 A2-B2, 192 Fibers, OFCP Aluminum Interlocked Armor, Sub-Units 2.0mm (16F), Yellow Jacket

Ships from and sold by A5 IT.

Part numbers

FIBM192AH is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #	Color	Putup Type	Order
FIBM192AH	Yellow	Reel	Order online

Product Category	Fiber Mini Distribution Cable
Suitable Applications	Data Center, RAN, Horizontal Backbone, Premise Backbone, Patching, Trunking

Number of Active Subunits	12
Fibers Per Subunit	16
Subunit Diameter	0.078 in (2.0 mm)
Subunit Color	Yellow
Fiber SubUnit Strength Members	Aramid Yarn
Central Strength Member Type	GRP

Inner Jacket Strength Member	Aramid Yarns
Material	PVC - Polyvinyl Chloride
Nominal Diameter@InnerJacket1 (cnv)	0.381 in (9.7 mm)
Color	Yellow
Number of Inner Jacket Ripcords	1

Armor Type and Material	AIA - Aluminum Interlock Armor

Wavelength	1310 nm	1550 nm
Max. Attenuation	0.40 dB/km	0.30 dB/km
10 Gigabit Ethernet Performance	10,000 m	50,000 m
40 Gigabit Ethernet Performance	10,000 m	--
100 Gigabit Ethernet Performance	10,000 m	--

Minimum Bend Radius During Installation	20x Cable OD
Minimum Bend Radius During Operation	10x Cable OD
Max. Tensile Strength During Installation	660 N (150 lbf)
Max. Tensile Strength During Operation	200 N (45 lbf)
Crush Resistance	440 N/cm
Bulk Cable Weight	232 lbs/kft (345 kg/km)

Installation Temperature Range	0°C to +60°C
Operating Temperature Range	0°C to +70°C
Storage Temperature Range	-40°C to +70°C

Environmental Suitability	Indoor
Flammability / Reaction to Fire	NFPA 262
NEC / UL Compliance	OFCP
CEC / C(UL) Compliance	FT6.
ICEA Compliance	S-83-596
TIA/EIA Compliance	568.3, 598-D
Telcordia Compliance	GR-409
European Directive Compliance	EU Directive 2015/863/EU (RoHS 2 amendment)
