Product Number: FI5M024A0

Indoor, Plenum, OM5, Mini-Distribution, 24 Fibers, Aluminum Interlocked, Lime Green Jacket

Name: Belden FI5M024A0
Brand: Belden
SKU: FI5M024A0

FX Indoor, OM5, Mini-Distribution, 24 Fibers, OFCP, Aluminum Interlocked Armor, 4.8mm (Double Jacket), Lime Green Jacket

Ships from and sold by A5 IT.

Specifications

Product Category	Fiber Mini Distribution Cable
Suitable Applications	Indoor, data center, patching, inside cabinets, workstation equipment connections

Subunit Diameter	0.118 in (3.0 mm)
Subunit Color	Lime Green
Fiber SubUnit Strength Members	Aramid Yarns

Inner Jacket Strength Member	Aramid Yarns
Material	PVC - Polyvinyl Chloride
Nominal Diameter@InnerJacket1 (cnv)	0.189 in (4.8 mm)
Color	Lime Green
Number of Inner Jacket Ripcords	1

Armor Type and Material	AIA - Aluminum Interlock Armor

Wavelength	850 nm	1300 nm
Max. Attenuation	3.0 dB/km	1.0 dB/km
10 Gigabit Ethernet Performance	550 m	1100 m
Min. Effective Modal Bandwidth (EMB)	4700 MHz.km	--
Min. Overfilled Launch (OFL) Bandwidth	3500 MHz.km	500 MHz.km

Minimum Bend Radius During Installation	20 x Cable OD
Minimum Bend Radius During Operation	10 x Cable OD
Max. Tensile Strength During Installation	660 N (150 lbf)
Max. Tensile Strength During Operation	200 N (45 lbf)
Crush Resistance	440 N/cm
Bulk Cable Weight	90.6 lbs/1000ft (134.8 kg/km)

Installation Temperature Range	0°C to +60°C
Operating Temperature Range	0°C to +70°C
Storage Temperature Range	-40°C to +70°C

Environmental Suitability	Indoor
Flammability / Reaction to Fire	NFPA 262
NEC / UL Compliance	OFCP
CEC / C(UL) Compliance	FT6.
ICEA Compliance	S-83-596
TIA/EIA Compliance	598-D
Telcordia Compliance	GR-409
European Directive Compliance	EU Directive 2015/863/EU (RoHS 2 amendment)
