Product Number: FI5M012P0

Indoor Plenum OM5 Mini-Distribution 12 Fibers Lime Green Jacket

Name: Belden FI5M012P0
Brand: Belden
SKU: FI5M012P0

FX Indoor, OM5, Mini-Distribution, 12 Fibers, OFNP, 4.8 mm (Double Jacket), Lime Green Jacket

Ships from and sold by A5 IT.

Specifications

Product Category	Fiber Mini Distribution Cable
Suitable Applications	Data Center, RAN, Horizontal Backbone, Premise Backbone, Patching, Trunking

Material	Thermoplastic
Nominal Diameter@InnerJacket1 (cnv)	0.120 in (3.0 mm)
Color	Lime Green

Wavelength	850 nm	953 nm	1300 nm
Max. Attenuation	3.0 dB/km	1.0 dB/km	1.0 dB/km
1 Gigabit Ethernet Performance			--
10 Gigabit Ethernet Performance	550 m	1100 m	1100 m
Min. Effective Modal Bandwidth (EMB)	4700 MHz.km	2470 MHz.km	--
Min. Overfilled Launch (OFL) Bandwidth	3500 MHz.km	1850 MHz.km	500 MHz.km

Minimum Bend Radius During Installation	15x Cable OD
Minimum Bend Radius During Operation	10x Cable OD
Max. Tensile Strength During Installation	660 N (150 lbf)
Max. Tensile Strength During Operation	200 N (45 lbf)
Crush Resistance	110 N/cm
Bulk Cable Weight	17 lbs/1000ft (25 kg/km)

Installation Temperature Range	0°C to +60°C
Operating Temperature Range	0°C to +70°C
Storage Temperature Range	-40°C to +70°C

Environmental Suitability	Indoor
Sustainability	CA Prop 65
Flammability / Reaction to Fire	OFNP, UL 910, FT6
NEC / UL Compliance	OFNP
CEC / C(UL) Compliance	OFNP.
ICEA Compliance	S-83-596
TIA/EIA Compliance	ANSI/ICEA S-83-596
European Directive Compliance	EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
