Product Number: FI4M024A2

Indoor Plenum OM4 Mini-Distribution 24 Fibers Aluminum Interlocked Erika Violet Jacket

Name: Belden FI4M024A2
Brand: Belden
SKU: FI4M024A2

FX Indoor, Multimode, OM4, Mini-Distribution, 24 Fibers, OFCP Aluminum Interlocked Armor, Erika Violet Jacket

Ships from and sold by A5 IT.

Part numbers

FI4M024A2 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #	Color	Putup Type	Order
FI4M024A2	Erika Violet	Reel	Order online
FI4M024A2	Erika Violet	Reel	Order online

Product Category	Fiber Mini Distribution Cable
Suitable Applications	Data Center, RAN, Horizontal Backbone, Premise Backbone, Patching, Trunking

Number of Active Subunits	2
Number of Fillers	2
Fibers Per Subunit	12
Subunit Diameter	0.118 in (3.0 mm)
Subunit Color	Erika Violet
Fiber SubUnit Strength Members	Aramid Yarns
Central Strength Member Type	GRP

Inner Jacket Strength Member	Aramid Yarns
Material	PVC - Polyvinyl Chloride
Nominal Diameter@InnerJacket1 (cnv)	0.380 in (9.7 mm)
Color	Erika Violet

Armor Type and Material	AIA - Aluminum Interlock Armor

Minimum Bend Radius During Installation	20x Cable OD
Minimum Bend Radius During Operation	10x Cable OD
Max. Tensile Strength During Installation	670 N (150 lbf)
Max. Tensile Strength During Operation	200 N (45 lbf)
Crush Resistance	440 N/cm
Bulk Cable Weight	174 lbs/kft (259 kg/km)

Installation Temperature Range	0°C to +60°C
Operating Temperature Range	0°C to +70°C
Storage Temperature Range	-40°C to +70°C

Environmental Suitability	Indoor
Sustainability	CA Prop 65
NEC / UL Compliance	OFCP
CEC / C(UL) Compliance	FT6.
ICEA Compliance	S-83-596
TIA/EIA Compliance	598-D
Telcordia Compliance	GR-409
European Directive Compliance	EU Directive 2015/863/EU (RoHS 2 amendment)
