FI4M008P0

Product Number: FI4M008P0

Indoor Mini Distribution OM4 8 Fibers OFNP 4.8 mm (Double Jacket) Erika Violet Jacket

FX Indoor, Mini Distribution, OM4, 8 Fibers, OFNP, 4.8 mm (Double Jacket), Erika Violet Jacket

Availability
Global
Status
Active
Request a quote

Ships from and sold by A5 IT.

Specifications

Product Overview

Product CategoryFiber Mini Distribution Cable
Suitable ApplicationsData Center, RAN, Horizontal Backbone, Premise Backbone, Patching, Trunking

Fiber Specifications

Fiber TypeOM4
Fiber Core Diameter50/125 μm
Fiber Diameter250 μm
Fiber Count8
Fiber Color CodingTIA-598-D

Inner Jacket Specifications

MaterialPVC - Polyvinyl Chloride
Nominal Diameter@InnerJacket1 (cnv)0.120 in (3.0 mm)
ColorErika Violet

Outer Jacket Specifications

Strength MemberAramid Yarns
Jacket MaterialPVC - Polyvinyl Chloride
Nom. Diameter0.190 in (4.8 mm)
Outer Jacket ColorErika Violet

Optical Characteristics

Wavelength850 nm1300 nm
40 Gigabit Ethernet Performance150 m--
100 Gigabit Ethernet Performance100 m--

Mechanical Characteristics

Minimum Bend Radius During Installation15x Cable OD
Bulk Cable Weight16 lbs/kft (23 kg/km)

Temperature Range

Operating Temperature Range0°C to +70°C
Storage Temperature Range-40°C to +70°C

Standards and Compliance

Environmental SuitabilityIndoor
Flammability / Reaction to FireNFPA 262, FT6
NEC / UL ComplianceOFNP
CEC / C(UL) ComplianceOFNP.
ICEA ComplianceS-83-596
TIA/EIA Compliance598-D
Telcordia ComplianceGR-409
European Directive ComplianceEU Directive 2015/863/EU (RoHS 2 amendment)

History

Update and RevisionRevision Number: 0.8 Revision Date: 12-05-2025
