Product Number: FDSM048A2

Indoor /Outdoor Mini-Distribution OS2 48 Fibers OFCP Aluminum Interlocked Armor Sub-Units 3.0mm (12F)

Name: Belden FDSM048A2
Brand: Belden
SKU: FDSM048A2

FX Indoor/Outdoor, Mini-Distribution, OS2, 48 Fibers, OFCP Aluminum Interlocked armor, Sub-Units 3.0mm (12F), Black Jacket

Ships from and sold by A5 IT.

Part numbers

FDSM048A2 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #	Color	Putup Type	Order
FDSM048A2	Black	Reel	Order online

Product Category	Fiber Mini Distribution Cable
Suitable Applications	Data Center, RAN, Horizontal Backbone, Premise Backbone, Patching, Trunking

Number of Active Subunits	4
Fibers Per Subunit	12
Subunit Diameter	0.118 in (3.0 mm)
Subunit Color	Yellow
Fiber SubUnit Strength Members	Aramid Yarns
Central Strength Member Type	GRP
Core Wrap Material	Water Block Tape

Inner Jacket Strength Member	Aramid Yarns
Material	PVC - Polyvinyl Chloride
Nominal Diameter@InnerJacket1 (cnv)	0.421 in (10.7 mm)
Color	Black
Number of Inner Jacket Ripcords	1

Armor Type and Material	AIA - Aluminum Interlock Armor

Wavelength	1310 nm	1550 nm
Max. Attenuation	0.50 dB/km	0.50 dB/km
10 Gigabit Ethernet Performance	10,000 m	50,000 m
40 Gigabit Ethernet Performance	10,000 m	--
100 Gigabit Ethernet Performance	10,000 m	--

Minimum Bend Radius During Installation	20 x Cable OD
Minimum Bend Radius During Operation	10x Cable OD
Max. Tensile Strength During Installation	1800 N (405 lbf)
Max. Tensile Strength During Operation	540 N (120 lbf)
Crush Resistance	440 N/cm
Bulk Cable Weight	241 lbs/kft (359 kg/km)

Installation Temperature Range	0°C to +60°C
Operating Temperature Range	-20°C to +70°C
Storage Temperature Range	-40°C to +70°C

Environmental Suitability	Indoor/Outdoor, Sunlight Resistance
Flammability / Reaction to Fire	NFPA 262
NEC / UL Compliance	OFCP
CEC / C(UL) Compliance	FT6.
ICEA Compliance	S-104-696
TIA/EIA Compliance	568.3, 598-D
European Directive Compliance	EU Directive 2015/863/EU (RoHS 2 amendment)
