Product Number: FDSM024P2

Indoor/Outdoor Plenum OS2 Mini-Distribution 24 Fibers 3mm SubUnit

Name: Belden FDSM024P2
Brand: Belden
SKU: FDSM024P2

FX Indoor/Outdoor, OS2, Mini-Distribution, 24 Fibers, OFNP, 12F/Sub-Unit (3.0mm), Black Jacket

Ships from and sold by A5 IT.

Part numbers

FDSM024P2 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Product Category	Fiber Mini Distribution Cable
Suitable Applications	Data Center, RAN, Horizontal Backbone, Premise Backbone, Patching, Trunking

Number of Active Subunits	2
Number of Fillers	2
Fibers Per Subunit	12
Subunit Diameter	0.118 in (3.0 mm)
Subunit Color	Yellow
Fiber SubUnit Strength Members	Waterblocking Aramid Yarns
Central Strength Member Type	GRP
Cable Core Water Blocking	Waterblock Tape

Minimum Bend Radius During Installation	15x Cable OD
Minimum Bend Radius During Operation	10x Cable OD
Max. Tensile Strength During Installation	1800 N (405 lbf)
Max. Tensile Strength During Operation	540 N (120 lbf)
Crush Resistance	220 N/cm
Bulk Cable Weight	65 lbs/kft

Installation Temperature Range	0°C to +60°C
Operating Temperature Range	-20°C to +70°C
Storage Temperature Range	-20°C to +70°C

Environmental Suitability	Indoor/Outdoor, Sunlight Resistance, UV Resistance, Burial
Flammability / Reaction to Fire	OFNP, UL 910, FT6
NEC / UL Compliance	OFNP
CEC / C(UL) Compliance	OFNP.
ICEA Compliance	S-104-696
TIA/EIA Compliance	ANSI/ICEA S-104-696
European Directive Compliance	EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
