Product Number: FDSM024A2Y

Indoor/Outdoor Plenum OS2 Mini-Distribution 24 Fibers Aluminum Interlocked 3mm Sub-Units Yellow Jacket

Name: Belden FDSM024A2Y
Brand: Belden
SKU: FDSM024A2Y

FX Indoor/Outdoor, OS2, Mini-Distribution, 24 Fibers, OFCP Aluminum Interlocked Armor, 12F/Sub-Units (3.0MM), Yellow Jacket

Ships from and sold by A5 IT.

Specifications

Product Category	Fiber Mini Distribution Cable
Suitable Applications	Data Center, RAN, Horizontal Backbone, Premise Backbone, Patching, Trunking

Number of Active Subunits	2
Number of Fillers	2
Fibers Per Subunit	12
Subunit Diameter	0.118 in (3.0 mm)
Subunit Color	Yellow
Fiber SubUnit Strength Members	Waterblocking Aramid Yarns
Central Strength Member Type	GRP
Cable Core Water Blocking	Waterblock Tape

Material	PVC - Polyvinyl Chloride
Nominal Diameter@InnerJacket1 (cnv)	0.318 in (8.1 mm)
Color	Yellow

Armor Type and Material	AIA - Aluminum Interlock Armor

Wavelength	1310 nm	1550 nm
Max. Attenuation	0.50 dB/km	0.50 dB/km
Mode Field Diameter	9.2 μm	10.4 μm
1 Gigabit Ethernet Performance	5,000 m	--
10 Gigabit Ethernet Performance	10,000 m	50,000 m

Minimum Bend Radius During Installation	20x Cable OD
Minimum Bend Radius During Operation	15x Cable OD
Max. Tensile Strength During Installation	1800 N (405 lbf)
Max. Tensile Strength During Operation	540 N (121 lbf)
Crush Resistance	440 N/cm
Bulk Cable Weight	284 lbs/kft (426 kg/km)

Installation Temperature Range	-10°C to +60°C
Operating Temperature Range	-20°C to +70°C
Storage Temperature Range	-40°C to +70°C

Environmental Suitability	Indoor/Outdoor, Sunlight Resistance, UV Resistance
Sustainability	CA Prop 65
NEC / UL Compliance	OFCP
CEC / C(UL) Compliance	FT6.
ICEA Compliance	S-104-696
TIA/EIA Compliance	598-D
Telcordia Compliance	GR-409
European Directive Compliance	EU Directive 2015/863/EU (RoHS 2 amendment)
