Product Number: FDSM012A0Y

Indoor/Outdoor Mini-Distribution OS2 12 Fibers OFCP Aluminum Interlocked Amor 4.8 mm (Double Jacket)

Name: Belden FDSM012A0Y
Brand: Belden
SKU: FDSM012A0Y

FX Indoor/Outdoor, Mini-Distribution, OS2, 12 Fibers, OFCP, Aluminum Interlocked Armor, 4.8 mm (Double Jacket), Yellow Jacket

Ships from and sold by A5 IT.

Part numbers

FDSM012A0Y is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Product Category	Fiber Mini Distribution Cable
Suitable Applications	Data Center, RAN, Horizontal Backbone, Premise Backbone, Patching, Trunking

Number of Active Subunits	1
Fibers Per Subunit	12
Subunit Diameter	0.130 in (3.3 mm)
Subunit Color	Yellow
Fiber SubUnit Strength Members	Waterblocking Aramid Yarn

Material	PVC - Polyvinyl Chloride
Nominal Diameter@InnerJacket1 (cnv)	0.265 IN (6.7 mm)
Color	Yellow
Number of Inner Jacket Ripcords	1

Armor Type and Material	AIA - Aluminum Interlock Armor

Jacket Material	PVDF - Polyvinylidene Fluoride
Nom. Diameter	0.551 in (14.1 mm)
Outer Jacket Color	Yellow

Wavelength	1310 nm	1550 nm
Max. Attenuation	0.5 dB/km	0.5 dB/km
10 Gigabit Ethernet Performance	10,000 m	50,000 m
40 Gigabit Ethernet Performance	10,000 m	--
100 Gigabit Ethernet Performance	10,000 m	--

Minimum Bend Radius During Installation	20x Cable OD
Minimum Bend Radius During Operation	10x Cable OD
Max. Tensile Strength During Installation	660 N (150 lbf)
Max. Tensile Strength During Operation	200 N (45 lbf)
Crush Resistance	440 N/cm
Bulk Cable Weight	158 lbs/kft (236 kg/km)

Installation Temperature Range	0°C to +60°C
Operating Temperature Range	-20°C to +70°C
Storage Temperature Range	-40°C to +70°C

Environmental Suitability	Indoor/Outdoor, Sunlight Resistance
Flammability / Reaction to Fire	NFPA 262, FT6
NEC / UL Compliance	OFCP
CEC / C(UL) Compliance	OFCP.
ICEA Compliance	S-104-696
TIA/EIA Compliance	598-D
European Directive Compliance	EU Directive 2015/863/EU (RoHS 2 amendment)
