Product Number: FD5M024P2

Indoor/Outdoor Plenum OM5 Mini-Distribution 24 Fibers 3mm SubUnit

Name: Belden FD5M024P2
Brand: Belden
SKU: FD5M024P2

FX Indoor/Outdoor, OM5, Mini-Distribution, 24 Fibers, OFNP, 12F/Sub-Unit (3.0mm), Black Jacket

Ships from and sold by A5 IT.

Part numbers

FD5M024P2 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Product Category	Fiber Mini Distribution Cable
Suitable Applications	Premise Backbone

Number of Active Subunits	2
Number of Fillers	2
Fibers Per Subunit	12
Subunit Diameter	0.120 in (3.0 mm)
Subunit Color	Lime Green
Fiber SubUnit Strength Members	Waterblocking Aramid Yarns
Central Strength Member Type	GRP
Cable Core Water Blocking	Waterblock Tape

Wavelength	850 nm	953 nm	1300 nm
Max. Attenuation	3.0 dB/km	1.0 dB/km	1.0 dB/km
10 Gigabit Ethernet Performance	550 m	1100 m	1100 m
Min. Effective Modal Bandwidth (EMB)	4700 MHz.km	2470 MHz.km	--
Min. Overfilled Launch (OFL) Bandwidth	3500 MHz.km	1850 MHz.km	500 MHz.km

Minimum Bend Radius During Installation	15x Cable OD
Minimum Bend Radius During Operation	10x Cable OD
Max. Tensile Strength During Installation	660 N (150 lbf)
Max. Tensile Strength During Operation	200 N (45 lbf)
Crush Resistance	220 N/cm

Installation Temperature Range	0°C to +60°C
Operating Temperature Range	-40°C to +70°C
Storage Temperature Range	-40°C to +70°C

Environmental Suitability	Indoor/Outdoor, Sunlight Resistance, UV Resistance
Flammability / Reaction to Fire	OFNP, UL 910, FT6
NEC / UL Compliance	OFNP
CEC / C(UL) Compliance	OFNP.
ICEA Compliance	S-104-696
TIA/EIA Compliance	ANSI/ICEA S-104-696
European Directive Compliance	EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
