Product Number: FD5M012A0

Indoor/Outdoor Plenum OM5 Mini-Distribution 12 Fibers Aluminum Interlocked

Name: Belden FD5M012A0
Brand: Belden
SKU: FD5M012A0

FX Indoor/Outdoor, OM5, Mini-Distribution, 12 Fibers, OFCP, Aluminum Interlocked Armor, 4.8mm (Double Jacket), Black Jacket

Ships from and sold by A5 IT.

Specifications

Product Category	Fiber Mini Distribution Cable
Suitable Applications	Data Center, RAN, Horizontal Backbone, Premise Backbone, Patching, Trunking

Number of Active Subunits	1
Fibers Per Subunit	12
Subunit Diameter	0.130 in (3.3 mm)
Subunit Color	Lime Green
Fiber SubUnit Strength Members	Waterblocking Aramid Yarns

Material	PVC - Polyvinyl Chloride
Nominal Diameter@InnerJacket1 (cnv)	0.265 in (6.7 mm)
Color	Black

Armor Type and Material	AIA - Aluminum Interlock Armor

Jacket Material	PVDF - Polyvinylidene Fluoride
Nom. Diameter	0.555 in (14.1 mm)
Outer Jacket Color	Black

Wavelength	850 nm	953 nm	1300 nm
Max. Attenuation	3.0 dB/km	1.0 dB/km	1.0 dB/km
10 Gigabit Ethernet Performance	550 m	1100 m	1100 m
Min. Effective Modal Bandwidth (EMB)	4700 MHz.km	2470 MHz.km	--
Min. Overfilled Launch (OFL) Bandwidth	3500 MHz.km	1850 MHz.km	500 MHz.km

Minimum Bend Radius During Installation	20x Cable OD
Minimum Bend Radius During Operation	10x Cable OD
Max. Tensile Strength During Installation	660 N (150 lbf)
Max. Tensile Strength During Operation	200 N (45 lbf)
Crush Resistance	440 N/cm
Bulk Cable Weight	186 lbs/kft (277 kg/km)

Installation Temperature Range	0°C to +60°C
Operating Temperature Range	-20°C to +70°C
Storage Temperature Range	-40°C to +70°C

Environmental Suitability	Indoor/Outdoor, Sunlight Resistance
Flammability / Reaction to Fire	NFPA 262
NEC / UL Compliance	OFCP
CEC / C(UL) Compliance	FT6.
ICEA Compliance	S-83-596
TIA/EIA Compliance	598-D
European Directive Compliance	EU Directive 2015/863/EU (RoHS 2 amendment)
