Indoor/Outdoor Plenum OM4 Mini-Distribution 48 Fibers Aluminum Interlocked 3mm Sub-Units Erika violet Jacket
FX Indoor/Outdoor, OM4, Mini-Distribution, 48 Fibers, OFCP Aluminum Interlocked Armor, 12F/Sub-Units (3.0MM), Erika Violet Jacket
- Availability
- Global
- Status
- Active
- Orderable items
- 1
Part numbers
FD4M048A2E is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | Order |
|---|---|---|
| FD4M048A2E | Erika Violet | Order online |
Specifications
Product Overview
| Product Category | Fiber Mini Distribution Cable |
|---|---|
| Suitable Applications | Data Center, RAN, Horizontal Backbone, Premise Backbone, Patching, Trunking |
Fiber Specifications
| Fiber Type | OM4 |
|---|---|
| Fiber Core Diameter | 50/125 μm |
| Fiber Diameter | 250 μm |
| Fiber Count | 48 |
| Fiber Color Coding | TIA-598-D |
Cable Construction
| Number of Active Subunits | 4 |
|---|---|
| Fibers Per Subunit | 12 |
| Subunit Diameter | 0.118 in (3.0 mm) |
| Subunit Color | Erika Violet |
| Fiber SubUnit Strength Members | Waterblocking Aramid Yarns |
| Central Strength Member Type | GRP |
| Cable Core Water Blocking | Waterblock Tape |
Inner Jacket Specifications
| Material | PVC - Polyvinyl Chloride |
|---|---|
| Nominal Diameter@InnerJacket1 (cnv) | 0.318 in (8.1 mm) |
| Color | Erika Violet |
Armor Specifications
| Armor Type and Material | AIA - Aluminum Interlock Armor |
|---|
Outer Jacket Specifications
| Jacket Material | PVC - Polyvinyl Chloride |
|---|---|
| Nom. Diameter | 0.608 in (15.4 mm) |
| Outer Jacket Color | Erika Violet |
Optical Characteristics
| Wavelength | 850 nm | 1300 nm |
|---|---|---|
| Max. Attenuation | 3.0 dB/km | 1.0 dB/km |
| 1 Gigabit Ethernet Performance | 1100 m | 550 m |
| 10 Gigabit Ethernet Performance | 550 m | -- |
| Min. Effective Modal Bandwidth (EMB) | 4700 MHz.km | -- |
| Min. Overfilled Launch (OFL) Bandwidth | 3500 MHz.km | 500 MHz.km |
Mechanical Characteristics
| Minimum Bend Radius During Installation | 20x Cable OD |
|---|---|
| Minimum Bend Radius During Operation | 15x Cable OD |
| Max. Tensile Strength During Installation | 1800 N (405 lbf) |
| Max. Tensile Strength During Operation | 540 N (121 lbf) |
| Crush Resistance | 440 N/cm |
| Bulk Cable Weight | 229 lbs/kft (341 kg/km) |
Temperature Range
| Installation Temperature Range | -10°C to +60°C |
|---|---|
| Operating Temperature Range | -20°C to +70°C |
| Storage Temperature Range | -40°C to +70°C |
Standards and Compliance
| Environmental Suitability | Indoor/Outdoor, Sunlight Resistance, UV Resistance |
|---|---|
| Sustainability | CA Prop 65 |
| NEC / UL Compliance | OFCP |
| CEC / C(UL) Compliance | FT6. |
| ICEA Compliance | S-104-696 |
| TIA/EIA Compliance | 598-D |
| Telcordia Compliance | GR-409 |
| European Directive Compliance | EU Directive 2015/863/EU (RoHS 2 amendment) |
History
| Update and Revision | Revision Number: 0.7 Revision Date: 12-04-2024 |
|---|
