Indoor/Outdoor Plenum OM4 Mini-Distribution 24 Fibers 3mm Sub-Units Black Jacket
FX Indoor/Outdoor, OM4, Mini-Distribution, 24 Fibers, OFNP, Sub-Units 3.0mm (12F), Black Jacket
- Availability
- Global
- Status
- Active
Specifications
Product Overview
| Product Category | Fiber Mini Distribution Cable |
|---|---|
| Suitable Applications | Data Center, RAN, Horizontal Backbone, Premise Backbone, Patching, Trunking |
Fiber Specifications
| Fiber Type | OM4 |
|---|---|
| Fiber Core Diameter | 50/125 μm |
| Fiber Diameter | 250 μm |
| Fiber Count | 24 |
| Fiber Color Coding | TIA-598-D |
Cable Construction
| Number of Active Subunits | 2 |
|---|---|
| Number of Fillers | 2 |
| Fibers Per Subunit | 12 |
| Subunit Diameter | 0.118 in (3.0 mm) |
| Subunit Color | Erika Violet |
| Fiber SubUnit Strength Members | Waterblocking Aramid Yarns |
| Central Strength Member Type | GRP |
| Core Wrap Material | Waterblock Tape |
Outer Jacket Specifications
| Jacket Material | PVC - Polyvinyl Chloride |
|---|---|
| Nom. Diameter | 0.421 in (10.7 mm) |
| Outer Jacket Color | Black |
| Outer Jacket Ripcord | 1 |
Optical Characteristics
| Wavelength | 850 nm | 1300 nm |
|---|---|---|
| Max. Attenuation | 3.0 dB/km | 1.0 dB/km |
| 10 Gigabit Ethernet Performance | 400 m | - |
| 40 Gigabit Ethernet Performance | 150 m | -- |
| 100 Gigabit Ethernet Performance | 100 m | -- |
| Min. Effective Modal Bandwidth (EMB) | 4700 MHz.km | - |
| Min. Overfilled Launch (OFL) Bandwidth | 3500 MHz.km | 500 MHz.km |
Mechanical Characteristics
| Minimum Bend Radius During Installation | 15x Cable OD |
|---|---|
| Minimum Bend Radius During Operation | 10x Cable OD |
| Max. Tensile Strength During Installation | 1800 N (405 lbf) |
| Max. Tensile Strength During Operation | 540 N (121 lbf) |
| Crush Resistance | 100 N/cm |
| Bulk Cable Weight | 65 lbs/kft (97 kg/km) |
Temperature Range
| Installation Temperature Range | 0°C to +60°C |
|---|---|
| Operating Temperature Range | -20°C to +70°C |
| Storage Temperature Range | -40°C to +70°C |
Standards and Compliance
| Environmental Suitability | Indoor/Outdoor, Sunlight Resistance |
|---|---|
| Flammability / Reaction to Fire | FT6, NFPA 262 |
| NEC / UL Compliance | OFNP |
| CEC / C(UL) Compliance | OFNP. |
| ICEA Compliance | S-104-696 |
| TIA/EIA Compliance | 598-D |
| European Directive Compliance | EU Directive 2015/863/EU (RoHS 2 amendment) |
History
| Update and Revision | Revision Number: 0.10 Revision Date: 12-02-2025 |
|---|
