Product Number: DKLU12MA006BKAA

Universal OFC MLT: Gel filling loose tubes(6f/T), Dry core, WB Tape + CST + Single LSZH Jacket (black) 6F G652D

Universal (Indoor/Outdoor) Gel filling loose tubes(6f/T) dry core optical fiber Multi Loose Tube cable with GRP, Water Blocking tape, Corrugated Steel Tape armor and Single LSZH jacket (black) 6F G652D

Availability: Asia Pacific
Status: Active

Ships from and sold by A5 IT.

Specifications

Product Overview

Environmental Space	Indoor/Outdoor
Suitable Applications	For outdoor and indoor use in structured (data) wiring systems such as industrial backbone, campus backbone, building backbone (riser) and/or horizontal cabling. For outdoor and indoor use in networks for industrial, telecom, cable TV and/or broadcast. Easy to install in ducts, tunnels and trenches and/or tubes. Suitable for Direct Burial.

Construction

Fiber Color Code	TIA-598-D
Central Strength Member Type	GRP
Cable Core Water Blocking	Waterblocking Yarns + Tape
Bulk Cable Weight	180 kg/km

Fiber Cable Construction

Fiber Type	OS2, G.652.D
Fiber Count	6
Subunit Color	Blue, Filler, Filler, Filler, Filler, Filler, Filler

Buffer Specification

Buffer Material	PBT – Polybutylene Terephthalate

SubUnit Specifications

Fibers Per Subunit	6

Physical Specifications

Type of Armor	Corrugated Steel Tape

Jacket Specifications

Number of Jackets	Single Jacket

Outer Jacket Specifications

Outer Jacket Ripcord	2

Outer Jacket

Material	LSZH - Low Smoke Zero Halogen (Flame Retardant)
Color	Black
Nominal Diameter	12.4 mm
Nominal Wall Thickness	1.8 mm

Optical Characteristics

Mode Field Diameter at 1310 nm	9.2 μm
Mode Field Diameter at 1550 nm	10.4 μm
Maximum Attenuation at 1310 nm	0.36 dB/km
Maximum Attenuation at 1550 nm	0.22 dB/km

Mechanical Characteristics

Mechanical Tests

Description	Tested Standard	Requirement/Value
Cable Min. Bend Radius Installation (Short Term)	IEC 60794-1-21-E11	20 x Cable OD
Cable Min. Bend Radius Operation (Long Term)	IEC 60794-1-21-E11	10 x Cable OD
Cable Max. Tensile Strength Installation (Short Term)	IEC 60794-1-21-E1	2000 N (450 lbf)
Cable Max. Tensile Strength Operation (Long Term)	IEC 60794-1-21-E1	600 N (135 lbf)
Cable Max. Crush Resistance Installation (Short Term)	IEC 60794-1-21-E3	1000 N/100mm

Temperature Range

Operating Temperature Range	-40 °C to +70 °C
Storage Temperature Range	-40 °C to +70 °C

Standards

IEC 60754-2 - Halogen Acid Gas Amount - Max. Conductivity	10 μS/mm
IEC Flammability	IEC 60332-1-2
IEC 60754-2 - Halogen Acid Gas Amount - Min. pH	4.3
IEC 61034-2 - Smoke Density Min. Transmittance	IEC 61034‐2
ISO/IEC Compliance	IEC 60793-1-1, IEC 60794-1-1
RoHS	Yes
UV/ Sunlight Protection	Yes

History

Update and Revision	Revision Number: 0.31 Revision Date: 12-21-2023
