D6UP

Product Number: D6UP

Category 6 Cable, 4 Pair, U/UTP, CMP

Category 6 Premise Horizontal Cable (250MHz), 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Plenum-CMP, Flamarrest® PVC-LS Jacket

Availability
Americas
Status
Active
Orderable items
9
Request a quoteOrder options (9)

Ships from and sold by A5 IT.

Part numbers

D6UP is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #ColorPutup TypeLengthOrder
D6UP 010U1000BlackUnReel1,000 ftOrder online
D6UP D15U1000BlueUnReel1,000 ftOrder online
D6UP 008U1000GrayUnReel1,000 ftOrder online
D6UP 005U1000Green, DarkUnReel1,000 ftOrder online
D6UP 003U1000OrangeUnReel1,000 ftOrder online
D6UP 002U1000RedUnReel1,000 ftOrder online
D6UP 007U1000VioletUnReel1,000 ftOrder online
D6UP 009U1000WhiteUnReel1,000 ftOrder online
D6UP 004U1000YellowUnReel1,000 ftOrder online

Specifications

Product Overview

Suitable ApplicationsPremise Horizontal Cable, Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, Surveillance, PoE++, PoE+, PoE
PatentThis product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents .

Construction Details

Overall Cable Diameter (Nominal)0.224 in (5.69 mm)

Conductor

Size23
StrandingSolid
MaterialBC - Bare Copper
No. of Pairs4

Insulation

MaterialPO+FEP - Polyolefin + Fluorinated Ethylene Propylene
Color CodeWhite/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown

Outer Jacket

MaterialPVC - Polyvinyl Chloride
Material Trade NameFlamarrest®
Nom. Diameter0.224 in (5.69 mm)
RipcordYes

Electrical Characteristics

Electricals

Max. Conductor DCR78 Ohm/km (24 Ohm/1000ft)
Max. Capacitance Unbalance330 pF/100m

Delay

Frequency100 MHz
Max. Delay537.6 ns/100m
Max. Delay Skew35 ns/100m
Nom. Velocity of Prop.72%

Voltage

UL Voltage Rating300 V (CMP)

Mechanical Characteristics

Max. Pull Tension25 lbs (11 kg)
Bulk Cable Weight25 lbs/1000ft (37 kg/km)

Temperature

UL Temperature75°C
Operating-20°C To +75°C
Installation0°C To +50°C
Storage-20°C To +75°C

Bend Radius

Stationary Min.1.0 in (25 mm)
Installation Min.2.25

Standards and Compliance

Environmental SuitabilityPlenum Indoor, Indoor
SustainabilityProduct LensTM, Environmental Product Declaration (EPD) Available
Flammability / Reaction to FireNFPA 262, UL 910 (Plenum)
CPR ComplianceCPR Euroclass: Eca
NEC / UL ComplianceCMP
CEC / C(UL) ComplianceCMP.
IEEE ComplianceIEEE 802.3bt Type 1, Type 2, Type 3, Type 4
Data CategoryCategory 6
TIA/EIA ComplianceANSI/TIA-568.2-D Category 6
Third Party Performance VerificationCategory 6
ISO/IEC ComplianceISO/IEC 11801-1, IEC 61156-5
European Directive ComplianceEU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2017-07-10
APAC ComplianceChina RoHS II (GB/T 26572-2011)
Non-Plenum NumberD6UR

Product Notes

NotesElectrical values are expected performance based on cable testing and representative performance within a typical Belden system.

History

Update and RevisionRevision Number: 0.190 Revision Date: 07-06-2026
