Product Number: BEL601

DataConnect CAT 6 UTP Cable

Name: Belden BEL601
Brand: Belden
SKU: BEL601

DataConnect CAT 6 UTP Cable, 4 Pairs, 24 AWG Solid Bare Copper Conductors, U/UTP, PVC Jacket, Indoor

Ships from and sold by A5 IT.

Part numbers

BEL601 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #	Color	Putup Type	Length	Order
BEL601 006U305M	Blue	Box	305 m	Order online

Suitable Applications	Belden DataConnect system is designed to provide standards-compliant cabling solutions for typical Ethernet data applications, include Retail shops, shopping malls & outlets, restaurants, bars/pubs, residential buildings etc., which is suitable for permanent & channel link installation

Overall Cable Diameter (Nominal)	5.7 mm (0.22 in)

Material	PE - Polyethylene

UL Voltage Rating	Max. 72 V DC

Bulk Cable Weight	39 Kg/km

Operating	-20°C To +60°C

Flammability / Reaction to Fire	CMX, IEC 60332-1-2
GB Compliance	GB/T 18380.1
CEC / C(UL) Compliance	C22.2 No.210.
Data Category	Category 6
TIA/EIA Compliance	TIA/EIA 568.2-D
ISO/IEC Compliance	IEC 11801 Class E
Other Standard Compliance(s)	AS/NZS1660.5.6
