Electronic, 1 C #20 Str TC, PVC-NYL Ins, OA TC Brd, PVC Jkt
Electronic, 1 Conductor 20AWG (19x32) Tinned Copper, PVC-NYL Insulation, Overall Tinned Copper Braid(90%) Shield, PVC Outer Jacket
- Availability
- Global
- Status
- Active
- Orderable items
- 2
Part numbers
9961 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | UPC | Order |
|---|---|---|---|
| 9961 0091000 | White | 612825265191 | Order online |
| 9961 009500 | White | 612825265207 | Order online |
Specifications
Product Overview
| Suitable Applications | MIL-W-16878 (Type B) Spec; up to 600V analog signals ; up to 600V voltage control |
|---|
Construction Details
| Overall Cable Diameter (Nominal) | 0.109 in. |
|---|
Conductor
| Element | Conductor(s) |
|---|---|
| No. of Elements | 1 |
| Size | 20 AWG |
| Stranding | 19x32 |
| Material | TC - Tinned Copper |
Insulation
| Element | Conductor(s) |
|---|---|
| Material | PVC - Polyvinyl Chloride |
| Nom. Thickness | 0.0105 in (0.267 mm) |
| Nom. Insulation Diameter | 0.064 in (1.6 mm) |
| Color Code | White |
Outer Shield
| Shield Type | Braid |
|---|---|
| Material | Tinned Copper (TC) |
| Coverage | 97% |
Outer Jacket
| Material | PVC - Polyvinyl Chloride |
|---|---|
| Nom. Thickness | 0.01 in (0.25 mm) |
| Nom. Diameter | 0.109 in |
Electrical Characteristics
| Nom Outer Shield DCR | 7.5 Ohm/1000ft (25 Ohm/km) |
|---|
Electricals
| Nom. Conductor DCR | 11.2 Ohm/1000ft |
|---|---|
| Nom. Capacitance Cond-to-Shield | 103 pF/ft (338 pF/m) |
| Max. Current | 3.8 Amps per Conductor at 25oC |
Voltage
| Voltage Rating | 600 V |
|---|
Mechanical Characteristics
| Max. Pull Tension | 15 lbs (6.8 kg) |
|---|---|
| Bulk Cable Weight | 8 lbs/1000ft |
Temperature
| UL Temperature | 105°C |
|---|---|
| Operating | -20°C To +105°C |
Bend Radius
| Stationary Min. | 1.09 in (27.7 mm) |
|---|---|
| Installation Min. | 1.09 in |
Standards and Compliance
| Flammability / Reaction to Fire | VW-1 |
|---|---|
| Military Compliance | MIL-W-16878E/17 (insulated conductor) |
| European Directive Compliance | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC Compliance | China RoHS II (GB/T 26572-2011) |
History
| Update and Revision | Revision Number: 0.391 Revision Date: 09-07-2025 |
|---|
