Electronic, 3 C #22 Sol BC, PO Ins, PVC Jkt, CM
Electronic, 3 Conductor 22AWG (Solid) Bare Copper, PO Insulation, PVC Outer Jacket, CM
- Availability
- Global
- Status
- Active
- Orderable items
- 2
Part numbers
8794 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | Putup Type | Length | UPC | Footnote | Order |
|---|---|---|---|---|---|---|
| 8794 6061000 | Gray, Rose | Reel | 1,000 ft | 612825216520 | C | Order online |
| 8794 606U1000 | Gray, Rose | UnReel | 1,000 ft | 612825216513 | — | Order online |
Specifications
Product Overview
| Suitable Applications | low voltage analog signals (4-20ma, 0-10v, ...); low voltage control (24v, ...); line level audio; voice communications; panel wiring |
|---|
Construction Details
| Overall Cable Diameter (Nominal) | 0.178 in. |
|---|
Conductor
| Element | Conductor(s) |
|---|---|
| No. of Elements | 3 |
| Size | 22 AWG |
| Stranding | Solid |
| Material | BC - Bare Copper |
Insulation
| Element | Conductor(s) |
|---|---|
| Material | PE - Polyethylene |
| Nom. Thickness | 0.018 in (0.46 mm) |
| Nom. Insulation Diameter | 0.062 in (1.6 mm) |
| Color Code | Green, Red, Yellow |
Outer Shield
| Material | No Shield |
|---|
Outer Jacket
| Material | PVC - Polyvinyl Chloride |
|---|---|
| Nom. Thickness | 0.022 in (0.56 mm) |
| Nom. Diameter | 0.178 in |
Electrical Characteristics
Electricals
| Nom. Conductor DCR | 18.36 Ohm/1000ft |
|---|---|
| Nom. Capacitance Cond-to-Cond | 16 pF/ft (52 pF/m) |
| Nom. Inductance | 0.22 μH/ft (0.72 μH/m) |
| Nom. Velocity of Prop. | 66% |
| Max. Current | 3 Amps per Conductor at 25oC |
Voltage
| UL Voltage Rating | 300 V |
|---|
Mechanical Characteristics
| Max. Pull Tension | 25.2 lbs (11.4 kg) |
|---|---|
| Bulk Cable Weight | 21 lbs/1000ft |
Temperature
| UL Temperature | 60°C |
|---|---|
| Operating | -30°C To +60°C |
Bend Radius
| Stationary Min. | 1.78 in (45.2 mm) |
|---|---|
| Installation Min. | 1.78 in |
Standards and Compliance
| Flammability / Reaction to Fire | UL 1685 UL Loading |
|---|---|
| NEC / UL Compliance | Article 800, CM |
| AWM Compliance | AWM 2093 |
| European Directive Compliance | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC Compliance | China RoHS II (GB/T 26572-2011) |
History
| Update and Revision | Revision Number: 0.394 Revision Date: 09-07-2025 |
|---|---|
| Footnote | C - CRATE REEL PUT-UP. |
