Product Number: 85230

Electronic, 2 C #20 Str TC, ETFE Ins, OS, ETFE Jkt

Name: Belden 85230
Brand: Belden
SKU: 85230

High Temperature Electronic, 2 Conductor 20AWG (7x28) Tinned Copper, ETFE Insulation, Overall Beldfoil® Shield, ETFE Outer Jacket

Ships from and sold by A5 IT.

Part numbers

85230 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #	Color	Putup Type	Length	UPC	Footnote	Order
85230 368500	Clear, Transparent	Reel	500 ft	612825212072	C	Order online
85230 3681000	Clear, Transparent	Reel	1,000 ft	612825212065	C	Order online

Suitable Applications	extreme high/low temperature environments; chemical resistant; low voltage analog signals (4-20ma, 0-10v, ...); low voltage control (24v, ...); instrumentation

Overall Cable Diameter (Nominal)	0.182 in (4.62 mm)

Element	Conductor(s)
Material	ETFE - Ethylene Tetrafluoroethylene
Nom. Thickness	0.015 in (0.38 mm)
Nom. Insulation Diameter	0.068 in (1.7 mm)
Color Code	Black, Red

Material	ETFE - Ethylene Tetrafluoroethylene
Nom. Thickness	0.020 in (0.51 mm)
Nom. Diameter	0.182 in (4.62 mm)

Nom Outer Shield DCR	9.57 Ohm/1000ft (31.4 Ohm/km)

Element	Conductor(s)
Nom. Conductor DCR	11.2 Ohm/1000ft
Nom. Capacitance Cond-to-Cond	31 pF/ft (100 pF/m)
Nom. Capacitance Cond-to-Other (Conds + Shield)	59 pF/ft (190 pF/m)
Nom. Characteristic Impedence	53 Ohm
Nom. Inductance	0.19 μH/ft (0.62 μH/m)
Max. Current	6.2 Amps per Conductor at 30oC

Voltage Rating	350 V

Max. Pull Tension	34.3 lbs (15.6 kg)
Bulk Cable Weight	25 lbs/1000ft

Operating	-30°C to +150°C

Stationary Min.	1.8 in (46 mm)
Installation Min.	1.8 in (46 mm)

Environmental Suitability	Indoor
Flammability / Reaction to Fire	UL 1581 (VW-1)
CPR Compliance	CPR Euroclass: Eca
European Directive Compliance	EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
UK Regulation Compliance	UKCA Mark
APAC Compliance	China RoHS II (GB/T 26572-2011)
